Canvas DrawImage() poor quality

25,194

enter image description here

You can incrementally scale your image down for better results.

Since your final size is 1/4 the original size, you could:

  • scale the 1000x669 image in half to 500x334 onto a temp canvas

  • scale the 500x335 canvas in half to 250x167 onto the main canvas

Here's example code and a Demo:

var canvas=document.getElementById("canvas");
var ctx=canvas.getContext("2d");
var cw=canvas.width;
var ch=canvas.height;

var img=new Image();
img.onload=start;
img.src="https://dl.dropboxusercontent.com/u/139992952/multple/wandio.png";
function start(){


  // scale the 1000x669 image in half to 500x334 onto a temp canvas
  var c1=scaleIt(img,0.50);

  // scale the 500x335 canvas in half to 250x167 onto the main canvas
  canvas.width=c1.width/2;
  canvas.height=c1.height/2;
  ctx.drawImage(c1,0,0,250,167);

}

function scaleIt(source,scaleFactor){
  var c=document.createElement('canvas');
  var ctx=c.getContext('2d');
  var w=source.width*scaleFactor;
  var h=source.height*scaleFactor;
  c.width=w;
  c.height=h;
  ctx.drawImage(source,0,0,w,h);
  return(c);
}
body{ background-color: ivory; padding:10px; }
canvas{border:1px solid red;}
<canvas id="canvas" width=300 height=300></canvas>

Share:
25,194

Related videos on Youtube

Dachi
Author by

Dachi

Updated on June 04, 2022

Comments

  • Dachi
    Dachi 20 days

    I have a problem with Html5 canvas

    i draw an image but its quality becomes very poor enter image description here

    after i draw it with canvas it becomes this

    enter image description here

    my code is here

    <script type="text/javascript">

    $canvasWidth = $('#canvas').width;
    $canvasHeight = $('#canvas').height;
    var alpha = 0.0;

    var canvas = document.getElementById('canvas');
    var ctx = canvas.getContext('2d');


    function draw(){
        var delta = 0.05;
        ctx.clearRect(0,0,$canvasWidth, $canvasHeight);
        ctx.globalAlpha = alpha;

        var logo= new Image();

        WandioLight.onload = function(){
            ctx.drawImage(logo, 0, 0, 250, 167);

        };

        logo.src = "logo.png";

        alpha += delta;
        if(alpha > 1.0){
            return false;
        }
        setTimeout(draw, 50);
    }
