Error obtaining UI hierarchy Error while obtaining UI hierarchy XML file: com.android.ddmlib.SyncException: Remote object doesn't exist

Question

I am testing my app with adb, but i get this error when i execute "dump view hierarchy for uiautomator":

Error obtaining UI hierarchy Error while obtaining UI hierarchy XML file: com.android.ddmlib.SyncException: Remote object doesn't exist!

My adb version is 1.0.36 and my android version is 6.0.1.

This error comes launched only when in the interface there is a dynamic element that is in motion.

thank you in advance.

Solution 1

The best way is to kill the adb server and start it again.

• sudo adb kill-server
• sudo adb start-server

This will do the trick.

Solution 2

Currently your UI needs to be idle (as in no Accessibility Events sent) for at least 1000ms before the AccessibilityService will be able to produce the UI hierarchy dump.

If you would try to run adb shell uiautomator dump it would give you the ERROR: could not get idle state.

Solution 3

Even though it's late I'm giving my observation here. Even I got this issue. Before taking the screen shot from UI Automator terminate the appium server connection. Then try to capture screenshot. It works fine.

Solution 4

I realise this is an old post. But I've noticed the same issue when I've use uiautomator to control the simulator for automation testing. It seems that the uiautomatorviewer does not connect to the emulator to take a screenshot after the emulator has been controlled by the uiautomator.

I found that running adb reconnect allows the uiautomatorviewer to take screenshots again.

Solution 5

Try Restarting your device, which worked in my case.

View more solutions

Comments

[Ale7]

if i wanted to test an app not made by me but with the same problem? thank you in advance.

[Alex P.]

it's a limitation of the AccessibilityService itself. I am guessing that an app changing its UI more frequently than once per second is not considered accessible

[Ale7]

therefore doesn't exist solution at this issue if i use adb? Thank you again.

[ospider]

That is correct, I have tried to restart my phone for several times, and It finally works

[GhostCat]

Reads more like a mediocre comment, not like an answer to the question.

[bjones01001101]

The commands worked for me, but I didn't need the sudo bit.

[Serg Buch]

In my case Appium server is not even running and I am still getting this error

[LexSav]

Don't forget to restart UIAutomator Viewer.

[Stuart]

try adb reconnect. I've had the same issue. once the app is controlled via adb, it locks to that source. adb reconnect unlocked it for uiautomatorviewer to gain control and take the screenshot.

[Mohsin Awan]

Same. I've tried all but still facing the same issue!

[Diego Torres Milano]

glad to hear it works in your case. A simple test that can be run in that situations, to verify the difference, is the one described at github.com/dtmilano/CulebraTester2-public#androidviewclient; including or excluding --use-uiautomator-helper should show a successful dump or the error. Another advantage is that the dump could be in json.
