How can I get xrandr to detect both nvidia cards: 2 x GTX480, triple-head?

25,079

Martin- Very similar setup on my end, except with a pair of nvidia GT9800's - circa 2008!. Also an onboard Intel HD4000 (disabled in bios). xrandr only showed 1 gpu, though all other sys related tools properly reported both. ubuntu 14.04 lts beta 2, nvidia 331.28 proprietary

The holy grail fix for me last night was: Base Mosaic! Empty xorg.conf, nvidia x server settings-> Enable Base Mosaic, then enable each detected display. It all just works! fast seemless multi-gpu, multi-head multi-monitor setup with 1 xscreen! My 3 displays are different resolutions and one is rotated portrait. Even the ubuntu Settings - Displays correctly shows all 3 monitors.

I suggest upgrading to the nvidia 331.28 proprietary drivers, blow out your xorg.conf, and try base Mosaic again.

-chad

➜ ~ nvidia-xconfig --query-gpu-info

Number of GPUs: 2
GPU #0:
  Name      : GeForce 9800 GT
  UUID      : GPU-56281125-01c7-ee85-b8b9-b3e5cf94b7c5
  PCI BusID : PCI:1:0:0
  Number of Display Devices: 1
  Display Device 0 (CRT-0):
      EDID Name             : Samsung SyncMaster
      Minimum HorizSync     : 30.000 kHz
      Maximum HorizSync     : 81.000 kHz
      Minimum VertRefresh   : 56 Hz
      Maximum VertRefresh   : 75 Hz
      Maximum PixelClock    : 146.250 MHz
      Maximum Width         : 1680 pixels
      Maximum Height        : 1050 pixels
      Preferred Width       : 1680 pixels
      Preferred Height      : 1050 pixels
      Preferred VertRefresh : 60 Hz
      Physical Width        : 470 mm
      Physical Height       : 300 mm
GPU #1:
  Name      : GeForce 9800 GT
  UUID      : GPU-cbc59e3f-e8c1-a347-a069-b62f6b885f7d
  PCI BusID : PCI:2:0:0
  Number of Display Devices: 2
  Display Device 0 (CRT-0):
      EDID Name             : Samsung SyncMaster
      Minimum HorizSync     : 30.000 kHz
      Maximum HorizSync     : 81.000 kHz
      Minimum VertRefresh   : 56 Hz
      Maximum VertRefresh   : 75 Hz
      Maximum PixelClock    : 140.000 MHz
      Maximum Width         : 1280 pixels
      Maximum Height        : 1024 pixels
      Preferred Width       : 1440 pixels
      Preferred Height      : 900 pixels
      Preferred VertRefresh : 60 Hz
      Physical Width        : 410 mm
      Physical Height       : 270 mm

  Display Device 1 (DFP-1):
      EDID Name             : Ancor Communications Inc ASUS VH242H
      Minimum HorizSync     : 30.000 kHz
      Maximum HorizSync     : 85.000 kHz
      Minimum VertRefresh   : 55 Hz
      Maximum VertRefresh   : 75 Hz
      Maximum PixelClock    : 160.000 MHz
      Maximum Width         : 1920 pixels
      Maximum Height        : 1080 pixels
      Preferred Width       : 1920 pixels
      Preferred Height      : 1080 pixels
      Preferred VertRefresh : 60 Hz
      Physical Width        : 520 mm
      Physical Height       : 290 mm

Below is my xorg.conf - All of which x server settings generated. Note that it is quite straight forward, and does not even reference my second GPU.

# nvidia-settings: X configuration file generated by nvidia-settings
# nvidia-settings:  version 331.20  ([email protected])  Mon Feb  3 15:07:22 UTC 2014

Section "ServerLayout"
    Identifier     "Layout0"
    Screen      0  "Screen0" 0 0
    InputDevice    "Keyboard0" "CoreKeyboard"
    InputDevice    "Mouse0" "CorePointer"
    Option         "Xinerama" "0"
EndSection

Section "Files"
EndSection

Section "InputDevice"

    # generated from default
    Identifier     "Mouse0"
    Driver         "mouse"
    Option         "Protocol" "auto"
    Option         "Device" "/dev/psaux"
    Option         "Emulate3Buttons" "no"
    Option         "ZAxisMapping" "4 5"
EndSection

Section "InputDevice"

    # generated from default
    Identifier     "Keyboard0"
    Driver         "kbd"
EndSection

Section "Monitor"

    # HorizSync source: edid, VertRefresh source: edid
    Identifier     "Monitor0"
    VendorName     "Unknown"
    ModelName      "Samsung SyncMaster"
    HorizSync       30.0 - 81.0
    VertRefresh     56.0 - 75.0
    Option         "DPMS"
EndSection

Section "Device"
    Identifier     "Device0"
    Driver         "nvidia"
    VendorName     "NVIDIA Corporation"
    BoardName      "GeForce 9800 GT"
    BusID          "PCI:1:0:0"
EndSection

Section "Screen"

auto-select +3600+0 {rotation=right}, GPU-cbc59e3f-e8c1-a347-a069-b62f6b885f7d.GPU-1.DVI-I-3: nvidia-auto-select +1680+180"
    Identifier     "Screen0"
    Device         "Device0"
    Monitor        "Monitor0"
    DefaultDepth    24
    Option         "Stereo" "0"
    Option         "nvidiaXineramaInfoOrder" "CRT-0"
    Option         "metamodes" "GPU-56281125-01c7-ee85-b8b9-b3e5cf94b7c5.GPU-0.DVI-I-0: nvidia-auto-select +0+180, GPU-cbc59e3f-e8c1-a347-a069-b62f6b885f7d.GPU-1.DVI-I-0: nvidia-auto-select +3600+0 {rotation=right}, GPU-cbc59e3f-e8c1-a347-a069-b62f6b885f7d.GPU-1.DVI-I-3: nvidia-auto-select +1680+180"
    Option         "MultiGPU" "Off"
    Option         "SLI" "off"
    Option         "BaseMosaic" "on"
    SubSection     "Display"
        Depth       24
    EndSubSection
EndSection
Share:
25,079

Related videos on Youtube

Martin Eve
Author by

Martin Eve

Updated on September 18, 2022

Comments

  • Martin Eve
    Martin Eve 5 months
    • I am running Linux Mint 16 (Petra)
    • I am running the default driver nvidia-319 shipped with the distro
    • I have 2x GTX480 cards
    • I have 3 monitors
    • Using the Nvidia driver, all monitors and GPUs are picked up by the proprietary utility.

    However, similarly to the report at https://devtalk.nvidia.com/default/topic/719768/linux/304-121-ubuntu-14-04-xrandr-1-4-multi-gpu-not-being-detected/ when I run xrandr --listproviders I am only shown a single provider -- the first card. I have xrandr 1.4, so should be able to see both. If I set up a separate X screen and then do xrandr --listproviders --screen 1, I can see the second card. However, I do not want multiple X screens; I want to be able to seamlessly flow between monitors.

    I do not want to run xinerama as it is a pain in the neck to setup and should be superseded by xrandr.

    Using the nouveau driver I can use all three screens exactly as I would like, but the performance is not good.

    So, I have a few questions:

    1.) Is this behaviour by design or a bug? I note at http://uk.download.nvidia.com/XFree86/Linux-x86/319.12/README/randr14.html that the driver only supports the Source Output capability; would that stop me just seeing two different card providers in xrandr?

    2.) If the former is true, is there a way that I can work around this?

    3.) I've played around with various basemosaic options, to no avail

    The last configuration I tried was:

    Section "ServerLayout"
        Identifier     "Layout0"
        Screen      0  "Screen0"
    EndSection

    Section "Monitor"

        # HorizSync source: edid, VertRefresh source: edid
        Identifier     "Monitor1"
        VendorName     "Unknown"
        ModelName      "Ancor Communications Inc ASUS VS247"
        HorizSync       24.0 - 83.0
        VertRefresh     50.0 - 75.0
        Option         "DPMS"
    EndSection

    Section "Monitor"

        # HorizSync source: edid, VertRefresh source: edid
        Identifier     "Monitor0"
        VendorName     "Unknown"
        ModelName      "LG Electronics W2243"
        HorizSync       30.0 - 83.0
        VertRefresh     56.0 - 75.0
        Option         "DPMS"
    EndSection

    Section "Monitor"

        # HorizSync source: unknown, VertRefresh source: unknown
        Identifier     "Monitor2"
        VendorName     "Unknown"
        ModelName      "AOC LM720/LM720A"
        HorizSync       30.0 - 83.0
        VertRefresh     55.0 - 75.0
        Option         "DPMS"
    EndSection

    Section "Device"
        Identifier     "Device1"
        Driver         "nvidia"
        VendorName     "NVIDIA Corporation"
        BoardName      "GeForce GTX 480"
        BusID          "PCI:1:0:0"
    EndSection

    Section "Device"
        Identifier     "Device0"
        Driver         "nvidia"
        VendorName     "NVIDIA Corporation"
        BoardName      "GeForce GTX 480"
        BusID          "PCI:1:0:0"
    EndSection

    Section "Device"
        Identifier     "Device2"
        Driver         "nvidia"
        VendorName     "NVIDIA Corporation"
        BoardName      "GeForce GTX 480"
        BusID          "PCI:2:0:0"
    EndSection

    Section "Screen"
        Identifier     "Screen0"
        Device         "Device0"
        Monitor        "Monitor0"
        DefaultDepth    24
        Option         "Stereo" "0"
        Option         "BaseMosaic" "True"
        Option         "MetaModes" "GPU-1.CRT-0: 1280x1024+0+0, GPU-0.CRT-0: 1920x1080+1280+0, GPU-0.DFP-2: 1920x1080+3200+0"
        SubSection     "Display"
            Depth       24
        EndSubSection
    EndSection

    Section "Screen"
        Identifier     "Screen1"
        Device         "Device1"
        Monitor        "Monitor1"
        DefaultDepth    24
        Option         "Stereo" "0"
        Option         "BaseMosaic" "True"
        Option         "MetaModes" "GPU-1.CRT-0: 1280x1024+0+0, GPU-0.CRT-0: 1920x1080+1280+0, GPU-0.DFP-2: 1920x1080+3200+0"
        SubSection     "Display"
            Depth       24
        EndSubSection
    EndSection

    Section "Screen"
        Identifier     "Screen2"
        Device         "Device2"
        Monitor        "Monitor2"
        DefaultDepth    24
        Option         "Stereo" "0"
        Option         "BaseMosaic" "True"
        Option         "MetaModes" "GPU-1.CRT-0: 1280x1024+0+0, GPU-0.CRT-0: 1920x1080+1280+0, GPU-0.DFP-2: 1920x1080+3200+0"
        SubSection     "Display"
            Depth       24
        EndSubSection
    EndSection


    The X log when running with no config is:

    [     6.896]
    X.Org X Server 1.14.5
    Release Date: 2013-12-12
    [     6.896] X Protocol Version 11, Revision 0
    [     6.896] Build Operating System: Linux 3.2.0-37-generic x86_64 Ubuntu
    [     6.896] Current Operating System: Linux theoria 3.11.0-12-generic #19-Ubuntu SMP Wed Oct 9 16:20:46 UTC 2013 x86_64
    [     6.896] Kernel command line: BOOT_IMAGE=/vmlinuz-3.11.0-12-generic root=UUID=3a6b3275-5e15-40c7-8de6-9eea1c63ebe1 ro quiet splash acpi_enforce_resources=lax
    [     6.896] Build Date: 17 December 2013  10:06:15AM
    [     6.896] xorg-server 2:1.14.5-1ubuntu2~saucy1 (For technical support please see http://www.ubuntu.com/support)
    [     6.896] Current version of pixman: 0.30.2
    [     6.896]    Before reporting problems, check http://wiki.x.org
        to make sure that you have the latest version.
    [     6.896] Markers: (--) probed, (**) from config file, (==) default setting,
        (++) from command line, (!!) notice, (II) informational,
        (WW) warning, (EE) error, (NI) not implemented, (??) unknown.
    [     6.896] (==) Log file: "/var/log/Xorg.0.log", Time: Wed Apr  9 07:12:33 2014
    [     6.897] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
    [     6.897] (==) No Layout section.  Using the first Screen section.
    [     6.897] (==) No screen section available. Using defaults.
    [     6.897] (**) |-->Screen "Default Screen Section" (0)
    [     6.897] (**) |   |-->Monitor "<default monitor>"
    [     6.898] (==) No monitor specified for screen "Default Screen Section".
        Using a default monitor configuration.
    [     6.899] (==) FontPath set to:
        /usr/share/fonts/X11/misc,
        /usr/share/fonts/X11/Type1,
        built-ins
    [     6.899] (==) ModulePath set to "/usr/lib/x86_64-linux-gnu/xorg/extra-modules,/usr/lib/xorg/extra-modules,/usr/lib/xorg/modules"
    [     6.899] (II) The server relies on udev to provide the list of input devices.
        If no devices become available, reconfigure udev or disable AutoAddDevices.
    [     6.899] (II) Loader magic: 0x7fe4b0739d20
    [     6.899] (II) Module ABI versions:
    [     6.899]    X.Org ANSI C Emulation: 0.4
    [     6.899]    X.Org Video Driver: 14.1
    [     6.899]    X.Org XInput driver : 19.1
    [     6.899]    X.Org Server Extension : 7.0
    [     6.900] (II) xfree86: Adding drm device (/dev/dri/card0)
    [     6.900] (II) xfree86: Adding drm device (/dev/dri/card1)
    [     6.901] (--) PCI:*(0:1:0:0) 10de:06c0:10de:075f rev 163, Mem @ 0xf4000000/33554432, 0xe0000000/134217728, 0xe8000000/67108864, I/O @ 0x0000e000/128, BIOS @ 0x????????/524288
    [     6.901] (--) PCI: (0:2:0:0) 10de:06c0:10de:075f rev 163, Mem @ 0xf0000000/33554432, 0xd0000000/134217728, 0xd8000000/67108864, I/O @ 0x0000d000/128, BIOS @ 0x????????/524288
    [     6.901] (II) Open ACPI successful (/var/run/acpid.socket)
    [     6.901] Initializing built-in extension Generic Event Extension
    [     6.901] Initializing built-in extension SHAPE
    [     6.901] Initializing built-in extension MIT-SHM
    [     6.901] Initializing built-in extension XInputExtension
    [     6.901] Initializing built-in extension XTEST
    [     6.901] Initializing built-in extension BIG-REQUESTS
    [     6.901] Initializing built-in extension SYNC
    [     6.901] Initializing built-in extension XKEYBOARD
    [     6.901] Initializing built-in extension XC-MISC
    [     6.901] Initializing built-in extension SECURITY
    [     6.901] Initializing built-in extension XINERAMA
    [     6.901] Initializing built-in extension XFIXES
    [     6.901] Initializing built-in extension RENDER
    [     6.901] Initializing built-in extension RANDR
    [     6.901] Initializing built-in extension COMPOSITE
    [     6.901] Initializing built-in extension DAMAGE
    [     6.901] Initializing built-in extension MIT-SCREEN-SAVER
    [     6.901] Initializing built-in extension DOUBLE-BUFFER
    [     6.901] Initializing built-in extension RECORD
    [     6.901] Initializing built-in extension DPMS
    [     6.901] Initializing built-in extension X-Resource
    [     6.901] Initializing built-in extension XVideo
    [     6.901] Initializing built-in extension XVideo-MotionCompensation
    [     6.901] Initializing built-in extension SELinux
    [     6.901] Initializing built-in extension XFree86-VidModeExtension
    [     6.901] Initializing built-in extension XFree86-DGA
    [     6.901] Initializing built-in extension XFree86-DRI
    [     6.901] Initializing built-in extension DRI2
    [     6.901] (II) "glx" will be loaded by default.
    [     6.901] (WW) "xmir" is not to be loaded by default. Skipping.
    [     6.901] (II) LoadModule: "dri2"
    [     6.901] (II) Module "dri2" already built-in
    [     6.901] (II) LoadModule: "glamoregl"
    [     6.903] (II) Loading /usr/lib/xorg/modules/libglamoregl.so
    [     6.964] (II) Module glamoregl: vendor="X.Org Foundation"
    [     6.964]    compiled for 1.14.3, module version = 0.5.1
    [     6.964]    ABI class: X.Org ANSI C Emulation, version 0.4
    [     6.964] (II) LoadModule: "glx"
    [     6.964] (II) Loading /usr/lib/x86_64-linux-gnu/xorg/extra-modules/libglx.so
    [     6.993] (II) Module glx: vendor="NVIDIA Corporation"
    [     6.993]    compiled for 4.0.2, module version = 1.0.0
    [     6.993]    Module class: X.Org Server Extension
    [     6.993] (II) NVIDIA GLX Module  319.60  Wed Sep 25 14:24:11 PDT 2013
    [     6.993] Loading extension GLX
    [     6.993] (==) Matched nvidia as autoconfigured driver 0
    [     6.993] (==) Matched nouveau as autoconfigured driver 1
    [     6.993] (==) Matched nvidia as autoconfigured driver 2
    [     6.993] (==) Matched nouveau as autoconfigured driver 3
    [     6.993] (==) Matched nvidia as autoconfigured driver 4
    [     6.993] (==) Matched nouveau as autoconfigured driver 5
    [     6.993] (==) Matched vesa as autoconfigured driver 6
    [     6.993] (==) Matched modesetting as autoconfigured driver 7
    [     6.993] (==) Matched fbdev as autoconfigured driver 8
    [     6.993] (==) Assigned the driver to the xf86ConfigLayout
    [     6.993] (II) LoadModule: "nvidia"
    [     6.994] (II) Loading /usr/lib/x86_64-linux-gnu/xorg/extra-modules/nvidia_drv.so
    [     7.001] (II) Module nvidia: vendor="NVIDIA Corporation"
    [     7.001]    compiled for 4.0.2, module version = 1.0.0
    [     7.001]    Module class: X.Org Video Driver
    [     7.002] (II) LoadModule: "nouveau"
    [     7.002] (II) Loading /usr/lib/xorg/modules/drivers/nouveau_drv.so
    [     7.004] (II) Module nouveau: vendor="X.Org Foundation"
    [     7.004]    compiled for 1.14.2.901, module version = 1.0.9
    [     7.004]    Module class: X.Org Video Driver
    [     7.004]    ABI class: X.Org Video Driver, version 14.1
    [     7.004] (II) LoadModule: "vesa"
    [     7.004] (II) Loading /usr/lib/xorg/modules/drivers/vesa_drv.so
    [     7.005] (II) Module vesa: vendor="X.Org Foundation"
    [     7.005]    compiled for 1.14.1, module version = 2.3.2
    [     7.005]    Module class: X.Org Video Driver
    [     7.005]    ABI class: X.Org Video Driver, version 14.1
    [     7.005] (II) LoadModule: "modesetting"
    [     7.005] (II) Loading /usr/lib/xorg/modules/drivers/modesetting_drv.so
    [     7.006] (II) Module modesetting: vendor="X.Org Foundation"
    [     7.006]    compiled for 1.14.1, module version = 0.8.0
    [     7.006]    Module class: X.Org Video Driver
    [     7.006]    ABI class: X.Org Video Driver, version 14.1
    [     7.006] (II) LoadModule: "fbdev"
    [     7.006] (II) Loading /usr/lib/xorg/modules/drivers/fbdev_drv.so
    [     7.007] (II) Module fbdev: vendor="X.Org Foundation"
    [     7.007]    compiled for 1.14.1, module version = 0.4.3
    [     7.007]    Module class: X.Org Video Driver
    [     7.007]    ABI class: X.Org Video Driver, version 14.1
    [     7.007] (II) NVIDIA dlloader X Driver  319.60  Wed Sep 25 14:04:14 PDT 2013
    [     7.007] (II) NVIDIA Unified Driver for all Supported NVIDIA GPUs
    [     7.007] (II) NOUVEAU driver Date:   Wed Jul 31 10:51:03 2013 +1000
    [     7.007] (II) NOUVEAU driver for NVIDIA chipset families :
    [     7.007]    RIVA TNT        (NV04)
    [     7.007]    RIVA TNT2       (NV05)
    [     7.007]    GeForce 256     (NV10)
    [     7.007]    GeForce 2       (NV11, NV15)
    [     7.007]    GeForce 4MX     (NV17, NV18)
    [     7.007]    GeForce 3       (NV20)
    [     7.007]    GeForce 4Ti     (NV25, NV28)
    [     7.007]    GeForce FX      (NV3x)
    [     7.008]    GeForce 6       (NV4x)
    [     7.008]    GeForce 7       (G7x)
    [     7.008]    GeForce 8       (G8x)
    [     7.008]    GeForce GTX 200 (NVA0)
    [     7.008]    GeForce GTX 400 (NVC0)
    [     7.008] (II) VESA: driver for VESA chipsets: vesa
    [     7.008] (II) modesetting: Driver for Modesetting Kernel Drivers: kms
    [     7.008] (II) FBDEV: driver for framebuffer: fbdev
    [     7.008] (++) using VT number 7

    [     7.021] (II) Loading sub module "fb"
    [     7.021] (II) LoadModule: "fb"
    [     7.021] (II) Loading /usr/lib/xorg/modules/libfb.so
    [     7.022] (II) Module fb: vendor="X.Org Foundation"
    [     7.022]    compiled for 1.14.5, module version = 1.0.0
    [     7.022]    ABI class: X.Org ANSI C Emulation, version 0.4
    [     7.022] (WW) Unresolved symbol: fbGetGCPrivateKey
    [     7.022] (II) Loading sub module "wfb"
    [     7.022] (II) LoadModule: "wfb"
    [     7.022] (II) Loading /usr/lib/xorg/modules/libwfb.so
    [     7.024] (II) Module wfb: vendor="X.Org Foundation"
    [     7.024]    compiled for 1.14.5, module version = 1.0.0
    [     7.024]    ABI class: X.Org ANSI C Emulation, version 0.4
    [     7.024] (II) Loading sub module "shadow"
    [     7.024] (II) LoadModule: "shadow"
    [     7.024] (II) Loading /usr/lib/xorg/modules/libshadow.so
    [     7.025] (II) Module shadow: vendor="X.Org Foundation"
    [     7.025]    compiled for 1.14.5, module version = 1.1.0
    [     7.025]    ABI class: X.Org ANSI C Emulation, version 0.4
    [     7.025] (II) Loading sub module "ramdac"
    [     7.025] (II) LoadModule: "ramdac"
    [     7.025] (II) Module "ramdac" already built-in
    [     7.026] (EE) [drm] KMS not enabled
    [     7.026] (WW) Falling back to old probe method for vesa
    [     7.026] (WW) Falling back to old probe method for modesetting
    [     7.026] (WW) Falling back to old probe method for fbdev
    [     7.026] (II) Loading sub module "fbdevhw"
    [     7.026] (II) LoadModule: "fbdevhw"
    [     7.026] (II) Loading /usr/lib/xorg/modules/libfbdevhw.so
    [     7.027] (II) Module fbdevhw: vendor="X.Org Foundation"
    [     7.027]    compiled for 1.14.5, module version = 0.0.2
    [     7.027]    ABI class: X.Org Video Driver, version 14.1
    [     7.027] (EE) open /dev/fb0: No such file or directory
    [     7.027] (II) NVIDIA(0): Creating default Display subsection in Screen section
        "Default Screen Section" for depth/fbbpp 24/32
    [     7.027] (==) NVIDIA(0): Depth 24, (==) framebuffer bpp 32
    [     7.027] (==) NVIDIA(0): RGB weight 888
    [     7.027] (==) NVIDIA(0): Default visual is TrueColor
    [     7.027] (==) NVIDIA(0): Using gamma correction (1.0, 1.0, 1.0)
    [     7.027] (**) NVIDIA(0): Enabling 2D acceleration
    [     7.627] (II) NVIDIA(GPU-0): Display (LG Electronics W2243 (CRT-0)) does not support NVIDIA
    [     7.627] (II) NVIDIA(GPU-0):     3D Vision stereo.
    [     7.656] (II) NVIDIA(GPU-0): Display (Ancor Communications Inc ASUS VS247 (DFP-2)) does not
    [     7.656] (II) NVIDIA(GPU-0):     support NVIDIA 3D Vision stereo.
    [     7.657] (II) NVIDIA(0): NVIDIA GPU GeForce GTX 480 (GF100) at PCI:1:0:0 (GPU-0)
    [     7.657] (--) NVIDIA(0): Memory: 1572864 kBytes
    [     7.657] (--) NVIDIA(0): VideoBIOS: 70.00.21.00.02
    [     7.657] (II) NVIDIA(0): Detected PCI Express Link width: 16X
    [     7.659] (--) NVIDIA(0): Valid display device(s) on GeForce GTX 480 at PCI:1:0:0
    [     7.659] (--) NVIDIA(0):     LG Electronics W2243 (CRT-0) (boot, connected)
    [     7.659] (--) NVIDIA(0):     CRT-1
    [     7.659] (--) NVIDIA(0):     DFP-0
    [     7.659] (--) NVIDIA(0):     DFP-1
    [     7.659] (--) NVIDIA(0):     Ancor Communications Inc ASUS VS247 (DFP-2) (connected)
    [     7.659] (--) NVIDIA(0): LG Electronics W2243 (CRT-0): 400.0 MHz maximum pixel clock
    [     7.659] (--) NVIDIA(0): CRT-1: 400.0 MHz maximum pixel clock
    [     7.659] (--) NVIDIA(0): DFP-0: 330.0 MHz maximum pixel clock
    [     7.659] (--) NVIDIA(0): DFP-0: Internal Single Link TMDS
    [     7.659] (--) NVIDIA(0): DFP-1: 165.0 MHz maximum pixel clock
    [     7.659] (--) NVIDIA(0): DFP-1: Internal Single Link TMDS
    [     7.659] (--) NVIDIA(0): Ancor Communications Inc ASUS VS247 (DFP-2): 330.0 MHz maximum pixel clock
    [     7.659] (--) NVIDIA(0): Ancor Communications Inc ASUS VS247 (DFP-2): Internal Dual Link TMDS
    [     7.659] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [     7.659] (**) NVIDIA(0):     device LG Electronics W2243 (CRT-0) (Using EDID
    [     7.659] (**) NVIDIA(0):     frequencies has been enabled on all display devices.)
    [     7.659] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [     7.660] (**) NVIDIA(0):     device Ancor Communications Inc ASUS VS247 (DFP-2) (Using
    [     7.660] (**) NVIDIA(0):     EDID frequencies has been enabled on all display
    [     7.660] (**) NVIDIA(0):     devices.)
    [     7.661] (==) NVIDIA(0):
    [     7.661] (==) NVIDIA(0): No modes were requested; the default mode "nvidia-auto-select"
    [     7.661] (==) NVIDIA(0):     will be used as the requested mode.
    [     7.661] (==) NVIDIA(0):
    [     7.661] (II) NVIDIA(0): Validated MetaModes:
    [     7.661] (II) NVIDIA(0):     "CRT-0:nvidia-auto-select{},DFP-2:nvidia-auto-select{}"
    [     7.661] (II) NVIDIA(0): Virtual screen size determined to be 3840 x 1080
    [     7.681] (--) NVIDIA(0): DPI set to (101, 101); computed from "UseEdidDpi" X config
    [     7.681] (--) NVIDIA(0):     option
    [     7.681] (II) UnloadModule: "vesa"
    [     7.681] (II) Unloading vesa
    [     7.681] (II) UnloadModule: "fbdev"
    [     7.681] (II) Unloading fbdev
    [     7.681] (II) UnloadSubModule: "fbdevhw"
    [     7.681] (II) Unloading fbdevhw
    [     7.681] (--) Depth 24 pixmap format is 32 bpp
    [     8.500] (II) NVIDIA(GPU-1): Found DRM driver nvidia-drm (20130102)
    [     8.571] (II) NVIDIA(GPU-1): Display (AOC LM720/LM720A (CRT-0)) does not support NVIDIA 3D
    [     8.571] (II) NVIDIA(GPU-1):     Vision stereo.
    [     8.575] (II) NVIDIA(GPU-1): NVIDIA GPU GeForce GTX 480 (GF100) at PCI:2:0:0 (GPU-1)
    [     8.575] (--) NVIDIA(GPU-1): Memory: 1572864 kBytes
    [     8.575] (--) NVIDIA(GPU-1): VideoBIOS: 70.00.21.00.02
    [     8.575] (II) NVIDIA(GPU-1): Detected PCI Express Link width: 16X
    [     8.575] (--) NVIDIA(GPU-1): Valid display device(s) on GeForce GTX 480 at PCI:2:0:0
    [     8.575] (--) NVIDIA(GPU-1):     AOC LM720/LM720A (CRT-0) (boot, connected)
    [     8.575] (--) NVIDIA(GPU-1):     CRT-1
    [     8.575] (--) NVIDIA(GPU-1):     DFP-0
    [     8.575] (--) NVIDIA(GPU-1):     DFP-1
    [     8.575] (--) NVIDIA(GPU-1):     DFP-2
    [     8.575] (--) NVIDIA(GPU-1): AOC LM720/LM720A (CRT-0): 400.0 MHz maximum pixel clock
    [     8.575] (--) NVIDIA(GPU-1): CRT-1: 400.0 MHz maximum pixel clock
    [     8.575] (--) NVIDIA(GPU-1): DFP-0: 330.0 MHz maximum pixel clock
    [     8.575] (--) NVIDIA(GPU-1): DFP-0: Internal Single Link TMDS
    [     8.575] (--) NVIDIA(GPU-1): DFP-1: 165.0 MHz maximum pixel clock
    [     8.575] (--) NVIDIA(GPU-1): DFP-1: Internal Single Link TMDS
    [     8.575] (--) NVIDIA(GPU-1): DFP-2: 330.0 MHz maximum pixel clock
    [     8.575] (--) NVIDIA(GPU-1): DFP-2: Internal Single Link TMDS
    [     8.575] (II) NVIDIA: Using 3072.00 MB of virtual memory for indirect memory
    [     8.575] (II) NVIDIA:     access.
    [     8.579] (II) NVIDIA(0): Setting mode "CRT-0:nvidia-auto-select{},DFP-2:nvidia-auto-select{}"
    [     8.662] Loading extension NV-GLX
    [     8.755] (==) NVIDIA(0): Disabling shared memory pixmaps
    [     8.755] (==) NVIDIA(0): Backing store disabled
    [     8.755] (==) NVIDIA(0): Silken mouse enabled
    [     8.755] (==) NVIDIA(0): DPMS enabled
    [     8.756] Loading extension NV-CONTROL
    [     8.756] Loading extension XINERAMA
    [     8.756] (II) Loading sub module "dri2"
    [     8.756] (II) LoadModule: "dri2"
    [     8.756] (II) Module "dri2" already built-in
    [     8.756] (II) NVIDIA(0): [DRI2] Setup complete
    [     8.756] (II) NVIDIA(0): [DRI2]   VDPAU driver: nvidia
    [     8.756] (--) RandR disabled
    [     8.759] (II) SELinux: Disabled on system
    [     8.759] (II) Initializing extension GLX
    [     8.771] (II) XKB: reuse xkmfile /var/lib/xkb/server-B20D7FC79C7F597315E3E501AEF10E0D866E8E92.xkm
    [     8.776] (II) config/udev: Adding drm device (/dev/dri/card0)
    [     8.776] (II) config/udev: Ignoring already known drm device (/dev/dri/card0)
    [   666.012] (II) NVIDIA(GPU-0): Display (LG Electronics W2243 (CRT-0)) does not support NVIDIA
    [   666.012] (II) NVIDIA(GPU-0):     3D Vision stereo.
    [   666.012] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   666.012] (**) NVIDIA(0):     device LG Electronics W2243 (CRT-0) (Using EDID
    [   666.012] (**) NVIDIA(0):     frequencies has been enabled on all display devices.)
    [   666.043] (II) NVIDIA(GPU-0): Display (Ancor Communications Inc ASUS VS247 (DFP-2)) does not
    [   666.043] (II) NVIDIA(GPU-0):     support NVIDIA 3D Vision stereo.
    [   666.043] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   666.043] (**) NVIDIA(0):     device Ancor Communications Inc ASUS VS247 (DFP-2) (Using
    [   666.043] (**) NVIDIA(0):     EDID frequencies has been enabled on all display
    [   666.043] (**) NVIDIA(0):     devices.)
    [   666.204] (II) NVIDIA(0): Setting mode "DVI-I-0: nvidia-auto-select @1920x1080 +1920+0 {ViewPortIn=1920x1080, ViewPortOut=1920x1080+0+0}, DVI-I-3: nvidia-auto-select @1920x1080 +1920+0 {ViewPortIn=1920x1080, ViewPortOut=1920x1080+0+0}"
    [   666.236] (II) NVIDIA(0): Setting mode "DVI-I-0: nvidia-auto-select @1920x1080 +1920+0 {ViewPortIn=1920x1080, ViewPortOut=1920x1080+0+0}, DVI-I-3: nvidia-auto-select @1920x1080 +0+0 {ViewPortIn=1920x1080, ViewPortOut=1920x1080+0+0}"
    [   666.345] (II) NVIDIA(GPU-0): Display (LG Electronics W2243 (CRT-0)) does not support NVIDIA
    [   666.345] (II) NVIDIA(GPU-0):     3D Vision stereo.
    [   666.345] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   666.345] (**) NVIDIA(0):     device LG Electronics W2243 (CRT-0) (Using EDID
    [   666.345] (**) NVIDIA(0):     frequencies has been enabled on all display devices.)
    [   666.376] (II) NVIDIA(GPU-0): Display (Ancor Communications Inc ASUS VS247 (DFP-2)) does not
    [   666.376] (II) NVIDIA(GPU-0):     support NVIDIA 3D Vision stereo.
    [   666.376] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   666.376] (**) NVIDIA(0):     device Ancor Communications Inc ASUS VS247 (DFP-2) (Using
    [   666.376] (**) NVIDIA(0):     EDID frequencies has been enabled on all display
    [   666.376] (**) NVIDIA(0):     devices.)
    [   667.413] (II) NVIDIA(GPU-0): Display (LG Electronics W2243 (CRT-0)) does not support NVIDIA
    [   667.413] (II) NVIDIA(GPU-0):     3D Vision stereo.
    [   667.413] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   667.413] (**) NVIDIA(0):     device LG Electronics W2243 (CRT-0) (Using EDID
    [   667.413] (**) NVIDIA(0):     frequencies has been enabled on all display devices.)
    [   667.444] (II) NVIDIA(GPU-0): Display (Ancor Communications Inc ASUS VS247 (DFP-2)) does not
    [   667.444] (II) NVIDIA(GPU-0):     support NVIDIA 3D Vision stereo.
    [   667.444] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   667.444] (**) NVIDIA(0):     device Ancor Communications Inc ASUS VS247 (DFP-2) (Using
    [   667.444] (**) NVIDIA(0):     EDID frequencies has been enabled on all display
    [   667.444] (**) NVIDIA(0):     devices.)
    [   667.560] (II) XKB: reuse xkmfile /var/lib/xkb/server-7996F6726817F73651B9DE0FDA11E35FC4524568.xkm
    [   667.568] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.724] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.727] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.730] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.733] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.736] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.739] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   668.742] (II) XKB: reuse xkmfile /var/lib/xkb/server-14B7503D830F6433941F279130885A2D664E08AA.xkm
    [   687.505] (II) NVIDIA(GPU-0): Display (LG Electronics W2243 (CRT-0)) does not support NVIDIA
    [   687.505] (II) NVIDIA(GPU-0):     3D Vision stereo.
    [   687.505] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   687.505] (**) NVIDIA(0):     device LG Electronics W2243 (CRT-0) (Using EDID
    [   687.505] (**) NVIDIA(0):     frequencies has been enabled on all display devices.)
    [   687.536] (II) NVIDIA(GPU-0): Display (Ancor Communications Inc ASUS VS247 (DFP-2)) does not
    [   687.536] (II) NVIDIA(GPU-0):     support NVIDIA 3D Vision stereo.
    [   687.536] (**) NVIDIA(0): Using HorizSync/VertRefresh ranges from the EDID for display
    [   687.536] (**) NVIDIA(0):     device Ancor Communications Inc ASUS VS247 (DFP-2) (Using
    [   687.536] (**) NVIDIA(0):     EDID frequencies has been enabled on all display
    [   687.536] (**) NVIDIA(0):     devices.)
    [  1212.601] (II) evdev: Eee PC WMI hotkeys: Close
    [  1212.601] (II) UnloadModule: "evdev"
    [  1212.601] (II) evdev: USB USB Keykoard: Close
    [  1212.601] (II) UnloadModule: "evdev"
    [  1212.601] (II) evdev: USB USB Keykoard: Close
    [  1212.601] (II) UnloadModule: "evdev"
    [  1212.601] (II) evdev: Microsoft Microsoft 5-Button Mouse with IntelliEye(TM): Close
    [  1212.601] (II) UnloadModule: "evdev"
    [  1212.601] (II) evdev: Power Button: Close
    [  1212.601] (II) UnloadModule: "evdev"
    [  1212.601] (II) evdev: Power Button: Close
    [  1212.601] (II) UnloadModule: "evdev"
    [  1212.860] (EE) Server terminated successfully (0). Closing log file.


    Any help would be very much appreciated.

    • Admin
      Admin almost 9 years
      I've snipped some of the log to keep to the character count
  • Martin Eve
    Martin Eve almost 9 years
    Hmm. Getting closer. Thanks for the help! I implemented a similar solution but now: [ 209.366] (EE) NVIDIA(GPU-0): Failed to find a valid Base Mosaic configuration. [ 209.366] (EE) NVIDIA(GPU-0): Invalid Base Mosaic configuration 1 of 1: [ 209.366] (EE) NVIDIA(GPU-0): GPUs: [ 209.366] (EE) NVIDIA(GPU-0): 1) NVIDIA GPU at PCI:1:0:0 [ 209.366] (EE) NVIDIA(GPU-0): 2) NVIDIA GPU at PCI:2:0:0 [ 209.366] (EE) NVIDIA(GPU-0): Errors: [ 209.366] (EE) NVIDIA(GPU-0): - The video link was not detected [ 209.366] (EE) NVIDIA(GPU-0): - Trouble accessing PCI Config Space
  • Martin Eve
    Martin Eve almost 9 years
    Did you install the SLI bridge (hardware)?
  • Martin Eve
    Martin Eve almost 9 years
    Thanks so much for the help @chadical. I played around a bit more and here's what finally worked: martineve.com/2014/04/15/… (you may want to update your answer but I will award bounty as it's now working!)
