How to merge YAML arrays?

Question

I would like to merge arrays in YAML, and load them via ruby -

some_stuff: &some_stuff
 - a
 - b
 - c
combined_stuff:
  <<: *some_stuff
  - d
  - e
  - f

I'd like to have the combined array as [a,b,c,d,e,f]

I receive the error: did not find expected key while parsing a block mapping

How do I merge arrays in YAML?

Solution 1

If the aim is to run a sequence of shell commands, you may be able to achieve this as follows:

# note: no dash before commands
some_stuff: &some_stuff |-
    a
    b
    c
combined_stuff:
  - *some_stuff
  - d
  - e
  - f

This is equivalent to:

some_stuff: "a\nb\nc"
combined_stuff:
  - "a\nb\nc"
  - d
  - e
  - f

I have been using this on my gitlab-ci.yml (to answer @rink.attendant.6 comment on the question).

---

Working example that we use to support requirements.txt having private repos from gitlab:

.pip_git: &pip_git
- git config --global url."https://gitlab-ci-token:${CI_JOB_TOKEN}@gitlab.com".insteadOf "ssh://[email protected]"
- mkdir -p ~/.ssh
- chmod 700 ~/.ssh
- echo "$SSH_KNOWN_HOSTS" > ~/.ssh/known_hosts
- chmod 644 ~/.ssh/known_hosts
test:
    image: python:3.7.3
    stage: test
    script:
        - *pip_git
        - pip install -q -r requirements_test.txt
        - python -m unittest discover tests
use the same `*pip_git` on e.g. build image...

where requirements_test.txt contains e.g.

-e git+ssh://[email protected]/example/[email protected]#egg=example

Solution 2

Update: 2019-07-01 14:06:12

• Note: another answer to this question was substantially edited with an update on alternative approaches.
  • That updated answer mentions an alternative to the workaround in this answer. It has been added to the See also section below.

Context

This post assumes the following context:

• python 2.7
• python YAML parser

Problem

lfender6445 wishes to merge two or more lists within a YAML file, and have those merged lists appear as one singular list when parsed.

Solution (Workaround)

This may be obtained simply by assigning YAML anchors to mappings, where the desired lists appear as child elements of the mappings. There are caveats to this, however, (see "Pitfalls" infra).

In the example below we have three mappings (list_one, list_two, list_three) and three anchors and aliases that refer to these mappings where appropriate.

When the YAML file is loaded in the program we get the list we want, but it may require a little modification after load (see pitfalls below).

Example

Original YAML file

  list_one: &id001
   - a
   - b
   - c
  list_two: &id002
   - e
   - f
   - g
  list_three: &id003
   - h
   - i
   - j
  list_combined:
      - *id001
      - *id002
      - *id003

Result after YAML.safe_load

## list_combined
  [
    [
      "a",
      "b",
      "c"
    ],
    [
      "e",
      "f",
      "g"
    ],
    [
      "h",
      "i",
      "j"
    ]
  ]

Pitfalls

• this approach produces a nested list of lists, which may not be the exact desired output, but this can be post-processed using the flatten method
• the usual caveats to YAML anchors and aliases apply for uniqueness and declaration order

Conclusion

This approach allows creation of merged lists by use of the alias and anchor feature of YAML.

Although the output result is a nested list of lists, this can be easily transformed using the flatten method.

See also

Updated alternative approach by @Anthon

• See alternative approach

Examples of the flatten method

• Javascript flatten ;; Merge/flatten an array of arrays
• Ruby flatten ;; http://ruby-doc.org/core-2.2.2/Array.html#method-i-flatten
• Python flatten ;; https://softwareengineering.stackexchange.com/a/254676/23884

Solution 3

This is not going to work:

1. merge is only supported by the YAML specifications for mappings and not for sequences

2. you are completely mixing things by having a merge key << followed by the key/value separator : and a value that is a reference and then continue with a list at the same indentation level

This is not correct YAML:

combine_stuff:
  x: 1
  - a
  - b

So your example syntax would not even make sense as a YAML extension proposal.

If you want to do something like merging multiple arrays you might want to consider a syntax like:

combined_stuff:
  - <<: *s1, *s2
  - <<: *s3
  - d
  - e
  - f

where s1, s2, s3 are anchors on sequences (not shown) that you want to merge into a new sequence and then have the d, e and f appended to that. But YAML is resolving these kind of structures depth first, so there is no real context available during the processing of the merge key. There is no array/list available to you where you could attach the processed value (the anchored sequence) to.

You can take the approach as proposed by @dreftymac, but this has the huge disadvantage that you somehow need to know which nested sequences to flatten (i.e. by knowing the "path" from the root of the loaded data structure to the parent sequence), or that you recursively walk the loaded data structure searching for nested arrays/lists and indiscriminately flatten all of them.

A better solution IMO would be to use tags to load data structures that do the flattening for you. This allows for clearly denoting what needs to be flattened and what not and gives you full control over whether this flattening is done during loading, or done during access. Which one to choose is a matter of ease of implementation and efficiency in time and storage space. This is the same trade-off that needs to be made for implementing the merge key feature and there is no single solution that is always the best.

E.g. my ruamel.yaml library uses the brute force merge-dicts during loading when using its safe-loader, which results in merged dictionaries that are normal Python dicts. This merging has to be done up-front, and duplicates data (space inefficient) but is fast in value lookup. When using the round-trip-loader, you want to be able to dump the merges unmerged, so they need to be kept separate. The dict like datastructure loaded as a result of round-trip-loading, is space efficient but slower in access, as it needs to try and lookup a key not found in the dict itself in the merges (and this is not cached, so it needs to be done every time). Of course such considerations are not very important for relatively small configuration files.

---

The following implements a merge like scheme for lists in python using objects with tag flatten which on-the-fly recurses into items which are lists and tagged toflatten. Using these two tags you can have YAML file:

l1: &x1 !toflatten
  - 1
  - 2
l2: &x2
  - 3
  - 4
m1: !flatten
  - *x1
  - *x2
  - [5, 6]
  - !toflatten [7, 8]

(the use of flow vs block style sequences is completely arbitrary and has no influence on the loaded result).

When iterating over the items that are the value for key m1 this "recurses" into the sequences tagged with toflatten, but displays other lists (aliased or not) as a single item.

One possible way with Python code to achieve that is:

import sys
from pathlib import Path
import ruamel.yaml
yaml = ruamel.yaml.YAML()
@yaml.register_class
class Flatten(list):
   yaml_tag = u'!flatten'
   def __init__(self, *args):
      self.items = args
   @classmethod
   def from_yaml(cls, constructor, node):
       x = cls(*constructor.construct_sequence(node, deep=True))
       return x
   def __iter__(self):
       for item in self.items:
           if isinstance(item, ToFlatten):
               for nested_item in item:
                   yield nested_item
           else:
               yield item
@yaml.register_class
class ToFlatten(list):
   yaml_tag = u'!toflatten'
   @classmethod
   def from_yaml(cls, constructor, node):
       x = cls(constructor.construct_sequence(node, deep=True))
       return x
data = yaml.load(Path('input.yaml'))
for item in data['m1']:
    print(item)

which outputs:

1
2
[3, 4]
[5, 6]
7
8

As you can see you can see, in the sequence that needs flattening, you can either use an alias to a tagged sequence or you can use a tagged sequence. YAML doesn't allow you to do:

- !flatten *x2

, i.e. tag an anchored sequence, as this would essentially make it into a different datastructure.

Using explicit tags is IMO better than having some magic going on as with YAML merge keys <<. If nothing else you now have to go through hoops if you happen to have a YAML file with a mapping that has a key << that you don't want to act like a merge key, e.g. when you make a mapping of C operators to their descriptions in English (or some other natural language).

Solution 4

If you only need to merge one item into a list you can do

fruit:
  - &banana
    name: banana
    colour: yellow
food:
  - *banana
  - name: carrot
    colour: orange

which yields

fruit:
  - name: banana
    colour: yellow
food:
  - name: banana
    colour: yellow
  - name: carrot
    colour: orange

Solution 5

Another way to enable merging arrays in python is by defining a !flatten tag. (This uses PyYAML, unlike Anthon's answer above. This may be necessary in cases when you don't have control over which package is used in the back end, e.g., anyconfig).

import yaml
yaml.add_constructor("!flatten", construct_flat_list)
def flatten_sequence(sequence: yaml.Node) -> Iterator[str]:
    """Flatten a nested sequence to a list of strings
        A nested structure is always a SequenceNode
    """
    if isinstance(sequence, yaml.ScalarNode):
        yield sequence.value
        return
    if not isinstance(sequence, yaml.SequenceNode):
        raise TypeError(f"'!flatten' can only flatten sequence nodes, not {sequence}")
    for el in sequence.value:
        if isinstance(el, yaml.SequenceNode):
            yield from flatten_sequence(el)
        elif isinstance(el, yaml.ScalarNode):
            yield el.value
        else:
            raise TypeError(f"'!flatten' can only take scalar nodes, not {el}")
def construct_flat_list(loader: yaml.Loader, node: yaml.Node) -> List[str]:
    """Make a flat list, should be used with '!flatten'
    Args:
        loader: Unused, but necessary to pass to `yaml.add_constructor`
        node: The passed node to flatten
    """
    return list(flatten_sequence(node))

This recursive flattening takes advantage of the PyYAML document structure, which parses all arrays as SequenceNodes, and all values as ScalarNodes. The behavior can be tested (and modified) in the following test function.

import pytest
def test_flatten_yaml():
    # single nest
    param_string = """
    bread: &bread
      - toast
      - loafs
    chicken: &chicken
      - *bread
    midnight_meal: !flatten
      - *chicken
      - *bread
    """
    params = yaml.load(param_string)
    assert sorted(params["midnight_meal"]) == sorted(
        ["toast", "loafs", "toast", "loafs"]
    )

View more solutions

Comments

[lfender6445]

to dry up duplication in a very large yaml file

[krak3n]

How is trying to be dry bad practice?

[rink.attendant.6]

@PatrickCollins I found this question trying to reduce duplication in my .gitlab-ci.yml file and unfortunately I have no control over the parser that GitLab CI uses :(

[Asclepius]

As a fallback, if the application code is also maintained by you, one can recursively merge them there, similar to how I did it here.

[Dariop]

Clever. I'm using it in our Bitbucket pipeline now. Thanks

[Mina Luke]

*The trailing dash is not required here, only the pipe at the end is enough. *This is an inferior solution since when the job fails on a very long multi-line statement it's not clear which command failed.

[Jorge Leitao]

@MinaLuke, inferior in comparison to what? None of the current answers provide a way to merge two items using only yaml... Moreover, there is nothing in the question stating that the OP wishes to use this in CI/CD. Finally, when this is used in CI/CD, logging only depends on the particular CI/CD used, not on the yaml declaration. So, if anything, the CI/CD that you are referring to is the one doing a bad job. The yaml in this answer is valid, and solves OP's problem.

[sm4rk0]

What's wrong with this answer? I don't mind downvotes if they are argumented. I'll keep the answer for people who can make use of it.

[Jorge Leitao]

Likely because this answer relies on jinja2 templating, when the question asks to do it in yml. jinja2 requires a Python environment, which is counter-productive if the OP is trying to DRY. Also, many CI/CD tools do not accept a templating step.

[sm4rk0]

Thanks @JorgeLeitao. That makes sense. I learned YAML and Jinja2 together while developing Ansible playbooks and templates and can't think about one without another

[niels]

@JorgeLeitao I guess you use it to combine Rules. Can you provide an working gitlabci example? I tried something based on your solution, but get always an validation error.

[Jorge Leitao]

@niels, I have added an example with a working gitlabci example. Note that some IDEs mark this yaml as invalid, even though it is not.

[kidbrax]

the key for me here was using - *stuff and not <<: *stuff

[Victor Ferreira]

it doesn't work for me. with - i get an error, like it trying to insert the list inside a list item. i dont know how to use the pipe. what was it for? how @Dariop manage to use it in BB Pipelines?

[haridsv]

Like @VictorFerreira mentioned, - *pip_git inserts a list in its place, so script would end up having 3 items, the first being a list of strings followed by 2 strings.

[Hi-Angel]

I'm suspicious about this. Please correct me if I'm wrong, but if it gets transformed to "a\nb\nc", this would mean gitlab-runner won't get a chance to check exit codes of a and b. So if any command in the sequence except the last one has failed, this wouldn't interrupt pipeline and runner would continue executing the rest of the commands..

[Pawel Gorczynski]

@JorgeLeitao Actually, your working example is a bit different (and better) then the actual answer ;)

[lead-free]

You can use extends keyword in gitlab ci to merge various sections of a job. docs.gitlab.com/ee/ci/yaml/#extends

[fool4jesus]

@lead-free It seems like that is only for merging objects. In docs.gitlab.com/ee/ci/yaml/… it says "script does not merge, but script: ['rake rspec'] overwrites script: ['echo "Hello world!"']. You can use YAML anchors to merge arrays." So extends doesn't take care of this use case (or mine).
