How to set size for local image using knitr for markdown?
Solution 1
You can also read the image using png
package for example and plot it like a regular plot using grid.raster
from the grid
package.
```{r fig.width=1, fig.height=10,echo=FALSE}
library(png)
library(grid)
img <- readPNG("path/to/your/image")
grid.raster(img)
```
With this method you have full control of the size of you image.
Solution 2
The question is old, but still receives a lot of attention. As the existing answers are outdated, here a more up-to-date solution:
Resizing local images
As of knitr
1.12, there is the function include_graphics
. From ?include_graphics
(emphasis mine):
The major advantage of using this function is that it is portable in the sense that it works for all document formats that
knitr
supports, so you do not need to think if you have to use, for example, LaTeX or Markdown syntax, to embed an external image. Chunk options related to graphics output that work for normal R plots also work for these images, such asout.width
andout.height
.
Example:
```{r, out.width = "400px"}
knitr::include_graphics("path/to/image.png")
```
Advantages:
- Over agastudy's answer: No need for external libraries or for re-rastering the image.
- Over Shruti Kapoor's answer: No need to manually write HTML. Besides, the image is included in the self-contained version of the file.
Including generated images
To compose the path to a plot that is generated in a chunk (but not included), the chunk options opts_current$get("fig.path")
(path to figure directory) as well as opts_current$get("label")
(label of current chunk) may be useful. The following example uses fig.path
to include the second of two images which were generated (but not displayed) in the first chunk:
```{r generate_figures, fig.show = "hide"}
library(knitr)
plot(1:10, col = "green")
plot(1:10, col = "red")
```
```{r}
include_graphics(sprintf("%sgenerate_figures-2.png", opts_current$get("fig.path")))
```
The general pattern of figure paths is [fig.path]/[chunklabel]-[i].[ext]
, where chunklabel
is the label of the chunk where the plot has been generated, i
is the plot index (within this chunk) and ext
is the file extension (by default png
in RMarkdown documents).
Solution 3
Un updated answer: in knitr 1.17
you can simply use
![Image Title](path/to/your/image){width=250px}
edit as per comment from @jsb
Note this works only without spaces, e.g. {width=250px} not {width = 250px}
Solution 4
Here's some options that keep the file self-contained without retastering the image:
Wrap the image in div
tags
<div style="width:300px; height:200px">
![Image](path/to/image)
</div>
Use a stylesheet
test.Rmd
---
title: test
output: html_document
css: test.css
---
## Page with an image {#myImagePage}
![Image](path/to/image)
test.css
#myImagePage img {
width: 400px;
height: 200px;
}
If you have more than one image you might need to use the nth-child pseudo-selector for this second option.
Solution 5
If you are converting to HTML, you can set the size of the image using HTML syntax using:
<img src="path/to/image" height="400px" width="300px" />
or whatever height and width you would want to give.
Related videos on Youtube
Adam Smith
Updated on July 15, 2022Comments
-
Adam Smith almost 2 years
I have a local image that I would like to include in an
.Rmd
file which I will thenknit
and convert to HTML slides withPandoc
. Per this post, this will insert the local image :
![Image Title](path/to/your/image)
Is there a way to modify this code to also set the image size?
-
Marius about 11 yearsFor finer control over sizes, you might end up having to use an HTML img tag
-
Ben Bolker about 11 yearssecond @Marius's comment:daringfireball.net/projects/markdown/syntax says "As of this writing, Markdown has no syntax for specifying the dimensions of an image; if this is important to you, you can simply use regular HTML <img> tags."
-
fabians over 9 yearsthe problem using HTML tags is that the image is no longer recognized as an external resource by the Rmd conversion process, so it won't be included in a stand-alone version of the rendered HTML.
-
-
Adam Smith about 11 yearsThank you, this works using slidy. (Does not work as well with dzslides, but I don't believe it's an issue with the provided solution).
-
Adam Smith about 11 yearsQuotes around filepath are required in
img <- readPNG("path/to/your/image")
but I wasn't able to edit the solution. -
agstudy about 11 years@AdamSmith I just copied your
path/to/your/image
from your question. Yes the path name is a string,, and you need quotes to define a string. Hope I am clear. -
fabians over 9 yearsthe problem with this solution is that the image is no longer recognized as an external resource by the Rmd conversion process, so it won't be included in a stand-alone version of the rendered HTML.
-
Paulo E. Cardoso over 9 yearsBy running this under RStudio, you will create a huge margin to the rendered png.
-
xhudik about 8 yearsthis is a good solution but it can be used with html output only! The other output will ignore the setting
-
CL. about 8 yearsFuture readers: This answer is outdated.
-
andybega about 8 yearsFor pdf output, you will have to specify units for the figure dimensions, e.g.
out.width='100pt'
, otherwise latex will throw an error about illegal unit of measure. -
Ben almost 8 yearsAlso works for MS Word output, but the out.width and out.height do not work
-
CL. over 7 years@andybega Thank you for your comment; I incorporated it into the answer.
-
Jameson Quinn over 7 yearsyou probably want
r, echo=FALSE, ...
-
jzadra almost 7 yearsThis is strange: it works with ioslides Rmd, but not with Rmd to word or html. For the latter two, I get errors: pandoc: Could not fetch ~/Google Drive/SI/DataScience/UAC_JRI/output/Master_Report/SI_logo.png ~/Google Drive/SI/DataScience/UAC_JRI/output/Master_Report/SI_logo.png: openBinaryFile: does not exist (No such file or directory)
-
CL. almost 7 years@jzadra Please create a new question with reproducible code for your issue. At the moment I cannot reproduce your issue (copied the second code snippet verbatim to an RMD file and knitted to HTML and Word).
-
jzadra almost 7 years
-
Dr. Mike over 6 yearsI tried this in knitr 1.16 and it didn't work when using ioslides. Has this feature then been removed or is it an ioslides issue?
-
user101089 over 6 yearsThe
<div> ... </div>
solution seems very simple. What is thestyle
setting to re-scale an image to a fixed percent, maintaining the aspect ratio? -
Nick Kennedy over 6 yearsTry using % instead of px.
-
slhck over 6 yearsDoes not work for me either, on the latest version of all packages.
-
Samuel about 6 yearsWorks for me using knitr 1.17. Make sure you write without spaces, e.g.
{width=250px}
not{width = 250px}
. -
warship about 6 yearsWorks for me, easiest solution by far.
-
InspectorSands about 6 yearsis this not exactly the same as my answer above?
-
Taylor Pellerin about 6 years@hermestrismegistus nearly, but I am using percent of width rather than pixel width. I found this option to be useful because in my particular case I was putting multiple images side by side, which behaved better this way that when I gave exact width
-
Lyngbakr over 5 yearsThis wouldn't work for me using
xaringan
withknitr_1.21
. -
André Costa about 5 yearsOn ioslides this is not working yet, using knitr_1.21
-
dsz almost 4 yearsFor height AND width
{height=640px width=480px}
- a space between the two, not a comma or anything else. -
giocomai almost 4 yearswith in percentage, e.g.
{width=100%}
works as well!
