How to write hello world in assembler under Windows?

207,621

Solution 1

NASM examples.

Calling libc stdio printf, implementing int main(){ return printf(message); }

; ----------------------------------------------------------------------------
; helloworld.asm
;
; This is a Win32 console program that writes "Hello, World" on one line and
; then exits.  It needs to be linked with a C library.
; ----------------------------------------------------------------------------
    global  _main
    extern  _printf
    section .text
_main:
    push    message
    call    _printf
    add     esp, 4
    ret
message:
    db  'Hello, World', 10, 0

Then run

nasm -fwin32 helloworld.asm
gcc helloworld.obj
a

There's also The Clueless Newbies Guide to Hello World in Nasm without the use of a C library. Then the code would look like this.

16-bit code with MS-DOS system calls: works in DOS emulators or in 32-bit Windows with NTVDM support. Can't be run "directly" (transparently) under any 64-bit Windows, because an x86-64 kernel can't use vm86 mode.

org 100h
mov dx,msg
mov ah,9
int 21h
mov ah,4Ch
int 21h
msg db 'Hello, World!',0Dh,0Ah,'$'

Build this into a .com executable so it will be loaded at cs:100h with all segment registers equal to each other (tiny memory model).

Good luck.

Solution 2

This example shows how to go directly to the Windows API and not link in the C Standard Library.

    global _main
    extern  [email protected]
    extern  [email protected]
    extern  [email protected]
    section .text
_main:
    ; DWORD  bytes;
    mov     ebp, esp
    sub     esp, 4
    ; hStdOut = GetstdHandle( STD_OUTPUT_HANDLE)
    push    -11
    call    [email protected]
    mov     ebx, eax
    ; WriteFile( hstdOut, message, length(message), &bytes, 0);
    push    0
    lea     eax, [ebp-4]
    push    eax
    push    (message_end - message)
    push    message
    push    ebx
    call    [email protected]
    ; ExitProcess(0)
    push    0
    call    [email protected]
    ; never here
    hlt
message:
    db      'Hello, World', 10
message_end:

To compile, you'll need NASM and LINK.EXE (from Visual studio Standard Edition)

   nasm -fwin32 hello.asm
   link /subsystem:console /nodefaultlib /entry:main hello.obj

Solution 3

These are Win32 and Win64 examples using Windows API calls. They are for MASM rather than NASM, but have a look at them. You can find more details in this article.

This uses MessageBox instead of printing to stdout.

Win32 MASM

;---ASM Hello World Win32 MessageBox
.386
.model flat, stdcall
include kernel32.inc
includelib kernel32.lib
include user32.inc
includelib user32.lib
.data
title db 'Win32', 0
msg db 'Hello World', 0
.code
Main:
push 0            ; uType = MB_OK
push offset title ; LPCSTR lpCaption
push offset msg   ; LPCSTR lpText
push 0            ; hWnd = HWND_DESKTOP
call MessageBoxA
push eax          ; uExitCode = MessageBox(...)
call ExitProcess
End Main

Win64 MASM

;---ASM Hello World Win64 MessageBox
extrn MessageBoxA: PROC
extrn ExitProcess: PROC
.data
title db 'Win64', 0
msg db 'Hello World!', 0
.code
main proc
  sub rsp, 28h
  mov rcx, 0       ; hWnd = HWND_DESKTOP
  lea rdx, msg     ; LPCSTR lpText
  lea r8,  title   ; LPCSTR lpCaption
  mov r9d, 0       ; uType = MB_OK
  call MessageBoxA
  add rsp, 28h
  mov ecx, eax     ; uExitCode = MessageBox(...)
  call ExitProcess
main endp
End

To assemble and link these using MASM, use this for 32-bit executable:

ml.exe [filename] /link /subsystem:windows
/defaultlib:kernel32.lib /defaultlib:user32.lib /entry:Main

or this for 64-bit executable:

ml64.exe [filename] /link /subsystem:windows
/defaultlib:kernel32.lib /defaultlib:user32.lib /entry:main

Why does x64 Windows need to reserve 28h bytes of stack space before a call? That's 32 bytes (0x20) of shadow space aka home space, as required by the calling convention. And another 8 bytes to re-align the stack by 16, because the calling convention requires RSP be 16-byte aligned before a call. (Our main's caller (in the CRT startup code) did that. The 8-byte return address means that RSP is 8 bytes away from a 16-byte boundary on entry to a function.)

Shadow space can be used by a function to dump its register args next to where any stack args (if any) would be. A system call requires 30h (48 bytes) to also reserve space for r10 and r11 in addition to the previously mentioned 4 registers. But DLL calls are just function calls, even if they're wrappers around syscall instructions.

Fun fact: non-Windows, i.e. the x86-64 System V calling convention (e.g. on Linux) doesn't use shadow space at all, and uses up to 6 integer/pointer register args, and up to 8 FP args in XMM registers.


Using MASM's invoke directive (which knows the calling convention), you can use one ifdef to make a version of this which can be built as 32-bit or 64-bit.

ifdef rax
    extrn MessageBoxA: PROC
    extrn ExitProcess: PROC
else
    .386
    .model flat, stdcall
    include kernel32.inc
    includelib kernel32.lib
    include user32.inc
    includelib user32.lib
endif
.data
caption db 'WinAPI', 0
text    db 'Hello World', 0
.code
main proc
    invoke MessageBoxA, 0, offset text, offset caption, 0
    invoke ExitProcess, eax
main endp
end

The macro variant is the same for both, but you won't learn assembly this way. You'll learn C-style asm instead. invoke is for stdcall or fastcall while cinvoke is for cdecl or variable argument fastcall. The assembler knows which to use.

You can disassemble the output to see how invoke expanded.

Solution 4

Flat Assembler does not need an extra linker. This makes assembler programming quite easy. It is also available for Linux.

This is hello.asm from the Fasm examples:

include 'win32ax.inc'
.code
  start:
    invoke  MessageBox,HWND_DESKTOP,"Hi! I'm the example program!",invoke GetCommandLine,MB_OK
    invoke  ExitProcess,0
.end start

Fasm creates an executable:

>fasm hello.asm
flat assembler  version 1.70.03  (1048575 kilobytes memory)
4 passes, 1536 bytes.

And this is the program in IDA:

enter image description here

You can see the three calls: GetCommandLine, MessageBox and ExitProcess.

Solution 5

To get an .exe with NASM'compiler and Visual Studio's linker this code works fine:

global WinMain
extern ExitProcess  ; external functions in system libraries
extern MessageBoxA
section .data
title:  db 'Win64', 0
msg:    db 'Hello world!', 0
section .text
WinMain:
    sub rsp, 28h
    mov rcx, 0       ; hWnd = HWND_DESKTOP
    lea rdx,[msg]    ; LPCSTR lpText
    lea r8,[title]   ; LPCSTR lpCaption
    mov r9d, 0       ; uType = MB_OK
    call MessageBoxA
    add rsp, 28h
    mov  ecx,eax
    call ExitProcess
    hlt     ; never here

If this code is saved on e.g. "test64.asm", then to compile:

nasm -f win64 test64.asm

Produces "test64.obj" Then to link from command prompt:

path_to_link\link.exe test64.obj /subsystem:windows /entry:WinMain  /libpath:path_to_libs /nodefaultlib kernel32.lib user32.lib /largeaddressaware:no

where path_to_link could be C:\Program Files (x86)\Microsoft Visual Studio 10.0\VC\bin or wherever is your link.exe program in your machine, path_to_libs could be C:\Program Files (x86)\Windows Kits\8.1\Lib\winv6.3\um\x64 or wherever are your libraries (in this case both kernel32.lib and user32.lib are on the same place, otherwise use one option for each path you need) and the /largeaddressaware:no option is necessary to avoid linker's complain about addresses to long (for user32.lib in this case). Also, as it is done here, if Visual's linker is invoked from command prompt, it is necessary to setup the environment previously (run once vcvarsall.bat and/or see MS C++ 2010 and mspdb100.dll).

Share:
207,621

Related videos on Youtube

Hoaz
Author by

Hoaz

Updated on July 08, 2022

Comments

  • Hoaz
    Hoaz 6 months

    I wanted to write something basic in assembly under Windows, I'm using NASM, but I can't get anything working.

    How to write and compile hello world without the help of C functions on Windows?

    • Jeremy
      Jeremy over 12 years
      Also check out Steve Gibson's Small Is Beautiful windows assembly starter kit.
    • Albert van der Horst
      Albert van der Horst almost 6 years
      Not using c-libraries is a somewhat strange constraint. One has to call some library within the MS-Windows operatings system. probably kernel32.dll.Whether Microsoft has written this in c or Pascal seems irrelevant. Is it meant that only OS-supplied functions can be called, what in a Unix-type system would be called system calls?
    • Rudy Velthuis
      Rudy Velthuis over 5 years
      With C libraries I assume he or she means without using an C runtime libraries like the ones that come with GCC or MSVC. Of course he or she will have to use some standard Windows DLLs, like kernel32.dll.
    • Albert van der Horst
      Albert van der Horst about 3 years
      The distinction between kernel32.dll and a gcc runtime library is not in the format (both are dll) and not in the language (both are probably c, but that is hidden.) The difference is between OS-supplied or not.
    • B''H Bi'ezras -- Boruch Hashem
      B''H Bi'ezras -- Boruch Hashem over 2 years
      Ive been looking for this also lol couldn't find anything with fasm without includes
  • mmx
    mmx over 13 years
    The question explicitly mentions "without using C libraries"
  • Bastien Léonard
    Bastien Léonard over 13 years
    There's no reliable way to do this without calling a C function at some point. Except if by "C function" you mean "standard C function".
  • MSalters
    MSalters over 13 years
    Wrong. The C library itself obviously can, so it's possible. It's only slightly harder, in fact. You just need to call WriteConsole() with the right 5 parameters.
  • Rômulo Ceccon
    Rômulo Ceccon over 13 years
    Although the second example doesn't call any C library function it's not a Windows program either. Virtual DOS Machine will be fired to run it.
  • David
    David over 13 years
    Yeah, the second example is one of the classics. Technically interrupt 0x21 is part of the DOS "API" - the interrupt pointed to a chunk of code installed into memory by DOS at startup, unlike the BIOS mapped interrupts which work even before an OS is loaded. Critical however for the ah=0x09 sub-function is that the string is terminated with $ (otherwise it just starts writing junk from memory). Alternatively you can also use the ah=0x40 function, for which you specify the number of characters (this function is also used to write to files, as the "screen" is just another pipe)
  • Alex Hart
    Alex Hart about 12 years
    Hey, out of interest, I was wondering why we need to offset the beginning of the program? Does this have to do with how the segments are set up? Like, does NASM place the data segment before the code segment in memory? (i.e. code breaks if org 0x100 set to org 0x00)
  • Asim Ihsan
    Asim Ihsan almost 11 years
    you likely need to include the kernel32.lib to link this (I did). link /subsystem:console /nodefaultlib /entry:main hello.obj kernel32.lib
  • Mas Biru
    Mas Biru almost 11 years
    @Alex Hart, his second example is for DOS, not for Windows. In DOS, the programs in tiny mode (.COM files, under 64Kb total code+data+stack) start at 0x100h because first 256 bytes in the segment are taken by the PSP (command-line args etc.). See this link: en.wikipedia.org/wiki/Program_Segment_Prefix
  • Annie
    Annie about 10 years
    +1 for your answer. Can you please add assembly code for Windows on ARM (WOA) too?
  • Paulo Pinto
    Paulo Pinto over 9 years
    This is not what was asked for. The first example uses the C library and the second one is MS-DOS, not Windows.
  • DarrenVortex
    DarrenVortex over 9 years
    How to do link the obj with ld.exe from MinGW?
  • towry
    towry about 9 years
    @DarrenVortex gcc hello.obj
  • Redoman
    Redoman about 8 years
    Would this also work using free linkers like Alink from sourceforge.net/projects/alink or GoLink from godevtool.com/#linker ? I don't want to install visual studio only for that?
  • Redoman
    Redoman about 8 years
    Does anybody know why to make it work I had to remove the underscores before _main and _printf ? I compiled it with: nasm -f win32 helloworld.asm -o hello.obj and linked it with golink /console /entry main hello.obj MSVCRT.dll. If I did not remove underscores I'd get the following error: Error! The following symbol was not defined in the object file or files:- _printf You may be trying to link object files or lib code with decorated symbols - If so, you could try using the /mix switch Output file not made
  • Admin
    Admin almost 8 years
    @OP "How to write and compile hello world without the help of C functions on Windows?"
  • Assad Ebrahim
    Assad Ebrahim over 7 years
    This is an excellent point --- ASM and C both rely on an OS provided function (_WriteFile in Windows). So where is the magic? It is in the device driver code for the video card.
  • Albert van der Horst
    Albert van der Horst almost 6 years
    This is thoroughly besides the point. The poster asks an assembler program that runs "under Windows". That means that Windows facilities can be used (e.g. kernel32.dll), but not other facilities like libc under Cygwin. For crying out loud, the poster explicitly says no c-libraries.
  • douggard
    douggard about 5 years
    Why does rsp require 0x28 bytes and not 0x20? All the references on the calling convention say that it should be 32 but it seems to require 40 in practice.
  • user3405291
    user3405291 almost 5 years
    In your 32-bit message box code, for some reason when I use title as label name, I run into errors. However when I use something else as label name like mytitle, everything works fine.
  • Peter Cordes
    Peter Cordes over 3 years
    I highly recommend using default rel at the top of your file so those addressing modes ([msg] and [title]) use RIP-relative addressing instead of 32-bit absolute.
  • Armen Michaeli
    Armen Michaeli over 2 years
    FASM may not use a linker but it still has to assemble a PE file. Which means that it actually doesn't just assemble code but also takes upon itself a job normally a linker would perform, and as such it's, in my humble opinion, misleading to call absense of a linker "hiding complexity", quite on the contrary -- the job an assembler is to assemble a program, but leave it to the linker to embed the program into a program image which may depend on a lot of things. As such, I find separation between a linker and an assembler a good thing, which it appears, you disagree on.
  • Albert van der Horst
    Albert van der Horst over 2 years
    @amn Think about it this way. If you use a linker to create above program, does it gives you more insight in what the program does, or what it consists of? If I look at the fasm source I know the complete structure of the program.
  • Albert van der Horst
    Albert van der Horst over 2 years
    This uses the standard c library which assumes the context of a c-compiler, not assembler. If the poster of this question acccepts this as the best solution, he absolutely must rephrase the question in particular "without the help of c-functions" .
  • Armen Michaeli
    Armen Michaeli over 2 years
    Fair point. On the flip side, separating linking from everything else has its benefits too. You normally have access to an object file (which goes a long way towards letting one inspect the structure of a program too, independent of the program image file format), you can invoke a different linker of your preference, with different options. It's about reusability and composability. With that in mind, FASM doing everything because it's "convenient" breaks those principles. I am not principally against it -- I see their justification for it -- but I, for one, don't need it.
  • B''H Bi'ezras -- Boruch Hashem
    B''H Bi'ezras -- Boruch Hashem over 2 years
    this uses an include and GUI how do we do it just to CMD with no includes at all?
  • B''H Bi'ezras -- Boruch Hashem
    B''H Bi'ezras -- Boruch Hashem over 2 years
    how to do it withoiut includes?
  • B''H Bi'ezras -- Boruch Hashem
    B''H Bi'ezras -- Boruch Hashem over 2 years
    get error for illegal isntruction on top line in fasm 64 bit windows
  • ceving
    ceving over 2 years
  • B''H Bi'ezras -- Boruch Hashem
    B''H Bi'ezras -- Boruch Hashem over 2 years
    can you point me to a section that writes to console without any dlls?
  • Albert van der Horst
    Albert van der Horst about 2 years
    @bluejayke Probably you didn't have the documentation for fasm at hand. FORMAT PE generates a 32 bits executable, which a 64 bit windows refuses to run. For a 64 bit program you want FORMAT PE64 . Also make sure you use proper 64 bit instructions in your program.
  • Albert van der Horst
    Albert van der Horst about 2 years
    The poster of the questions wants to know, how someone would write printf based on the facilities Windows provides, so this is again totally besides the point.
  • Nik
    Nik about 2 years
    Thank you for explaining how to link! You saved my mental health. I was starting to pull my hair out over 'error LNK2001: unresolved external symbol ExitProcess' and similar errors...
  • Captain Segfault
    Captain Segfault almost 2 years
    I don't see how kernel32.dll is not a C (or at least C++) library. There are reasonable interpretations of what this questioner (or others asking similar questions) really meant to ask. "... e.g. kernel32.dll" is a fairly good one. ("e.g. int 21h" was the one I implicitly took, which is obviously dated now, but in 2009 64 bit Windows was the exception.) Other answers here cover those effectively; the point of this answer is to point out that this isn't quite the right question.
  • sgraham
    sgraham over 1 year
    @douggard It's a little confusing, but that's because the a) the stack alignment needs to be maintained at 16, and b) the return address is pushed by call. So adding 0x20 is for the shadow, +8 for return address, +8 to maintain alignment.
  • Aritro Shome
    Aritro Shome about 1 year
    @PhiS just curious is there any learning resource for MASM, that used ml.exe / ml64.exe? Because the precious little learning material online says that we've got to use masm sdk which for some reason doesn't really agree with my machine :( .
  • Peter Cordes
    Peter Cordes 9 months
    This question is tagged [x86] [nasm], so this ARM answer isn't fully on-topic here. IDK how many future readers will find it, especially if you don't even mention ARM Windows in text outside your code (I edited to fix the code formatting and fix that). A self-answered Q&A might be a better place for it, but it's probably fine to leave this answer here even though the question is primarily about [x86].
  • Nicolás Abram
    Nicolás Abram 8 months
    The MASM64 example gives a syntax error, it seems title is a directive: docs.microsoft.com/en-us/cpp/assembler/masm/title?view=msvc-‌​170 Using another name works fine
  • Lorenzo
    Lorenzo 6 months
    After ExitProcess an exception gets thrown saying "Access violation reading location 0xFFFFFFFFFFFFFFFFF on the x64 version
