Kali-Linux VM doesn't get ip when connecting to wireless connection

Question

I am setting up my Kali Linux VM hosted in Virtual box to work through the wireless interface on my computer. I need to access few tools from the host machine, so I want to have an IP for this machine that I can use, Here is how ifconfig output looks like.

When I have wired connection to the computer itself, the eth0 interface shows an ip address and everything works great. However, when my computer is connected to wireless, I don't seem to get anything working. Here is how virtual-box settings for the VM.

Its probably obvious from my question that I am a newbie to linux, I'll appreciate if some step-by-step type of method could be described that can help solve this issue.

UPDATE If Attached to is set to NAT, this is what I see in ifconfig. Still cannot access internet etc.

UPDATE-2 After Sam3000 suggestions, below is what I get

Solution

I have come across the following as a potential solution, so its worth a try:

1. Shut down your VM.
2. Open up VirtualBox - your VM should be powered off
3. Click on your VM
4. Click settings
5. Click Network
6. You should have adapter 1: (Enable Network Adapter checked) Adapter type: Intel PRO/1000 MT Desktop, Attached to: NAT, Name: (blank)
7. Click on adapter 2 - here you will create a new adapter.. Adapter type: Intel PRO/1000 MT Desttop, Attached to: Bridged Adapter, Name: en1:[Pick a name, no square brackets]
8. Click OK
9. Start your VM and test

Comments

[paul deter]

so adopter type Intel PRO/1000 MT Desktop is same both? Does it matter if I don't have wireless adopter in one of the two?

[paul deter]

oh wait, I don't get Intel PRO/1000 MT Desktop with Bridget Adopter as an option. Apart from Dell Wireless (as in image in my question), other option is Intel(R) 82579LM Gigabit Network Connection.. Which one should I select here?

[Unencoded]

Make sure you're looking at the "Adapter Type" menu, and not the "attached to" menu, easy mistake to make

[paul deter]

yeah i was looking at wrong place :). Let me try it now

[paul deter]

updated question with image based on your suggestion

[Unencoded]

So today I tried to re-create the problem at my end with a Kali Linux VM, but I haven't been able to, the connection is fine when using my wireless adapter. I have come across a few more ideas though, so I'll leave the chat window open if you wish to discuss things further :)
