MySQL error: Missing index for constraint

Question

I am creating 2 tables in my database:

DROP TABLE IF EXISTS `med_pharmacy`;
CREATE TABLE IF NOT EXISTS `med_pharmacy` (
  `med_pharmacy_id` int(11) NOT NULL AUTO_INCREMENT,
  `med_id` int(11) NOT NULL,
  `med_barcode` varchar(45) DEFAULT NULL,
  `med_received` date DEFAULT NULL,
  `med_expiry` date DEFAULT NULL,
  `med_tablet` int(11) DEFAULT NULL,
  `med_pill` int(11) DEFAULT NULL,
  `clinic_id` varchar(45) DEFAULT NULL,
  PRIMARY KEY (`med_pharmacy_id`),
  KEY `fk_med_pharmacy_medication1_idx` (`med_id`)
) ENGINE=InnoDB AUTO_INCREMENT=1261 DEFAULT CHARSET=utf8mb4;

AND:

DROP TABLE IF EXISTS `medication`;
CREATE TABLE `medication` (
  `med_id` int(11) NOT NULL,
  `med_name` varchar(75) NOT NULL,
  `med_date_added` date DEFAULT NULL,
  `clinic_id` varchar(45) DEFAULT NULL,
  `med_type` varchar(15) DEFAULT NULL
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4;

And when I run the queries in wamp I got this error:

SQL query:

ALTER TABLE `med_pharmacy`
ADD CONSTRAINT `fk_med_pharmacy_medication1`
FOREIGN KEY (`med_id`)
REFERENCES
`medication` (`med_id`) ON DELETE CASCADE ON UPDATE CASCADE MySQL

said: Documentation

#1822 - Failed to add the foreign key constaint. Missing index for constraint 'fk_med_pharmacy_medication1' in the referenced table 'medication'

The tables already exists but I changed one field.

Solution 1

The column referenced in a foreign key must be indexed. You need to add an index on medication.med_id. In fact, this should probably be the primary key of the table.

ALTER TABLE medication ADD PRIMARY KEY (med_id);

Solution 2

if you are giving

ADD CONSTRAINT `fk_med_pharmacy_medication1`
FOREIGN KEY (`med_id`)

A FOREIGN KEY constraint does not have to be linked only to a PRIMARY KEY constraint in another table; it can also be defined to reference the columns of a UNIQUE constraint in another table.

so med_id should have primary key in medication or reference the columns of a UNIQUE constraint

Comments

[alim1990]

but I already had in my sql script the following: ALTER TABLE medication` ADD PRIMARY KEY (med_id);`

[Shadow]

No, it does not.

[alim1990]

but I already had in my sql script the following: ALTER TABLE medication` ADD PRIMARY KEY (med_id);`

[Barmar]

I suspect you have that after you try to add the foreign key. It has to be before it.

[alim1990]

Yeah I think that

[Barmar]

Why don't you just put these things in your CREATE TABLE queries, instead of doing them separately with ALTER TABLE?

[alim1990]

because I exported the sql file from phpmyadmin. I am surprised as you.
