(ROSE plot error) Error: Faceting variables must have at least one value

15,237

Solution 1

The problem is in the line:

dat$Date <- as.POSIXct(paste0(dat$YY,dat$MM,dat$DD),format="%Y,%m,%d")

You did not correctly specify the formatting which rendered dat$Date to be filled with NA

dat$Date <- as.POSIXct(paste(dat$YY,dat$MM,dat$DD),format="%Y %m %d") #there are no `,` separating them with `paste0`
dat$Year <- as.numeric(format(dat$Date,"%Y"))
dat$month <- factor(format(dat$Date,"%B"),levels=month.name)

p1 <- plot.windrose(data=dat,spd="WSPD",dir="WDIR")
p2 <- p1 + facet_wrap(~month,ncol=4)

enter image description here

Solution 2

In case this helps someone else: I came across this error because I had ZERO records in my data frame (due to a pipe & filter) and didn't even realize it.

Share:
15,237

Related videos on Youtube

Lyndz
Author by

Lyndz

Cool,New Programmer

Updated on June 04, 2022

Comments

  • Lyndz
    Lyndz over 1 year

    I am trying to plot monthly roseplots in R using the code below but I am encountering an error: "Error: Faceting variables must have at least one value"

    Here is the data that I am using Link to data

    This code came from a previous post: Rose plot using ggplot

    require(ggplot2)
    require(RColorBrewer)
    require(scales)

    plot.windrose <- function(data,
                          spd,
                          dir,
                          spdres = 2,
                          dirres = 22.5,
                          spdmin = 2,
                          spdmax = 20,
                          spdseq = NULL,
                          palette = "YlGnBu",
                          countmax = NA,
                          debug = 0){


      # Look to see what data was passed in to the function
      if (is.numeric(spd) & is.numeric(dir)){
      # assume that we've been given vectors of the speed and direction vectors
       data <- data.frame(spd = spd,
                       dir = dir)
       spd = "spd"
       dir = "dir"
      } else if (exists("data")){
      # Assume that we've been given a data frame, and the name of the speed
      # and direction columns. This is the format we want for later use.
      }

      # Tidy up input data ----
      n.in <- NROW(data)
      dnu <- (is.na(data[[spd]]) | is.na(data[[dir]]))
      data[[spd]][dnu] <- NA
      data[[dir]][dnu] <- NA

    # figure out the wind speed bins ----
    if (missing(spdseq)){
      spdseq <- seq(spdmin,spdmax,spdres)
    } else {
      if (debug >0){
         cat("Using custom speed bins \n")
      }
    }
    # get some information about the number of bins, etc.
    n.spd.seq <- length(spdseq)
    n.colors.in.range <- n.spd.seq - 1

    # create the color map
    spd.colors <- colorRampPalette(brewer.pal(min(max(3,
                                                    n.colors.in.range),
                                                min(9,
                                                    n.colors.in.range)),
                                            palette))(n.colors.in.range)

     if (max(data[[spd]],na.rm = TRUE) > spdmax){
     spd.breaks <- c(spdseq,
                    max(data[[spd]],na.rm = TRUE))
     spd.labels <- c(paste(c(spdseq[1:n.spd.seq-1]),
                          '-',
                          c(spdseq[2:n.spd.seq])),
                    paste(spdmax,
                          "-",
                          max(data[[spd]],na.rm = TRUE)))
     spd.colors <- c(spd.colors, "grey50")
     } else{
     spd.breaks <- spdseq
     spd.labels <- paste(c(spdseq[1:n.spd.seq-1]),
                        '-',
                        c(spdseq[2:n.spd.seq]))
     }
     data$spd.binned <- cut(x = data[[spd]],
                         breaks = spd.breaks,
                         labels = spd.labels,
                         ordered_result = TRUE)

      # clean up the data
      data. <- na.omit(data)

      # figure out the wind direction bins
      dir.breaks <- c(-dirres/2,
                  seq(dirres/2, 360-dirres/2, by = dirres),
                  360+dirres/2)
      dir.labels <- c(paste(360-dirres/2,"-",dirres/2),
                  paste(seq(dirres/2, 360-3*dirres/2, by = dirres),
                        "-",
                        seq(3*dirres/2, 360-dirres/2, by = dirres)),
                  paste(360-dirres/2,"-",dirres/2))
      # assign each wind direction to a bin
      dir.binned <- cut(data[[dir]],
                    breaks = dir.breaks,
                    ordered_result = TRUE)
      levels(dir.binned) <- dir.labels
      data$dir.binned <- dir.binned

      # Run debug if required ----
      if (debug>0){
        cat(dir.breaks,"\n")
        cat(dir.labels,"\n")
        cat(levels(dir.binned),"\n")

      }

      # create the plot ----
      p.windrose <- ggplot(data = na.omit(data),
                       aes(x = dir.binned,
                           fill = spd.binned
                           ,y = (..count..)/sum(..count..)
                           ))+
        geom_bar() +
        scale_x_discrete(drop = FALSE,
                     labels = c("N","NNE","NE","ENE", "E",
                                "ESE", "SE","SSE",
                                "S","SSW", "SW","WSW", "W",
                                 "WNW","NW","NNW")) +
        coord_polar(start = -((dirres/2)/360) * 2*pi) +
        scale_fill_manual(name = "Wind Speed (m/s)",
                      values = spd.colors,
                       drop = FALSE) +
        theme(axis.title.x = element_blank(),axis.title=element_text(size=15),
        axis.text=element_text(colour="black",size=12,family="serif"),
        legend.text=element_text(size=12),legend.title=element_text(size=12)) +
        scale_y_continuous(labels = percent) +
        ylab("Frequency")

       # adjust axes if required
      if (!is.na(countmax)){
        p.windrose <- p.windrose +
      ylim(c(0,countmax))
      }

      # print the plot
      print(p.windrose)

      # return the handle to the wind rose
      return(p.windrose)
    }

    ##Read Data

    dat<-read.csv("test.csv",header=T,sep=",")
    dat[dat==-20]<-NA
    dat[dat==-2]<-NA
    dat[dat==-1]<-0
    dat[dat==-10]<-0


    dat$Date <- as.POSIXct(paste0(dat$YY,dat$MM,dat$DD),format="%Y,%m,%d")
    dat$Year <- as.numeric(format(dat$Date,"%Y"))
    dat$month <- factor(format(dat$Date,"%B"),levels=month.name)

    #p1 <- plot.windrose(data=dat,spd = dat$WSPD,dir = dat$WDIR,spdseq=c(0,2,4,6,8,10,12,14,16,18,20))

    p1 <- plot.windrose(data=dat,spd="WSPD",dir="WDIR")
    p2 <- p1 + facet_wrap(~month,ncol=4)
    outImg <- paste0("Infanta",".png")

    ggsave(outImg,p2)
    dev.off()


    Questions

    [1] Any suggestions on how to do this correctly in R?

    • Lyndz
      Lyndz over 5 years
      @missuse--I have this line" dat$month <- factor(format(dat$Date,"%B"),levels=month.name), I will use this for labelling the plots. I also tried your suggestion but I still got the same error.
    • missuse
      missuse over 5 years
      I apologize I saw it now in your post.
    • IRTFM
      IRTFM over 2 years
      Well, that's unfortunate. The link to "data' has been deleted.
  • Lyndz
    Lyndz over 5 years
    !.Thank you so much. I also noticed the NA values in the Date column but I did not how to correct it. Awesome!
  • monkey
    monkey about 2 years
    given how many people have fallen into this trapdoor, should this be the accepted answer!
