Why is my Wacom Intuos tablet not detected?

13.04 usb hardware wacom graphics-tablet

51,478

Solution 1

Im running Ubuntu 13.10, I downloaded the kernel driver v0.20 and followed instructions from Linux Wacom SourceForge Project, and my CTL-480 is working flawlessly.

Solution 2

EDIT: According to this forum post new drivers that support this device were released a few weeks ago. I don't know what the status on these drivers is in Ubuntu yet but they have turned up in ArchLinux and some other places and you can always install them manually while you wait on distro releases.

The CTL-480 tablet is not supported by the currently released wacom input driver for Linux. Support for the model has been added to the code base and is expected to be in the 0.20 version of the driver (0.19 is current as of this writing). Device IDs and other things have also been submitted to the linux kernel so that they are properly recognized in the future.

I don't have an ETA for support, but expect this to work out of the box in the coming months.

In the mean time it will only work if you manually compile the drivers after applying the various patches submitted for supporting this model.

51,478

Caleb

I am a former moderator of the Christianity and Biblical Hermeneutics Stack Exchange sites who resigned in protest because I could no longer in good faith support the parent company with my volunteer time when they are enforcing conformity to ideologies openly antagonistic to my beliefs and because their treatment of other volunteer moderators has been reprehensibly poor. I am a scripting language connoisseur, regular expression aficionado, network geek, general lover of Linux and a frequent contributor to open source software. I transitioned to programming from other work because I was too busy automating my own work environment to actually do the other work. I have a hobby interest in cartography. For more see my personal site. Most importantly, my life is defined by the grace of God given to men through Jesus Christ. It is my ambition that everything I do would reflect His glory and point people towards Him.

Updated on September 18, 2022

Comments

Caleb over 1 year
I need a little help trying to install a Wacom Intuos tablet, model number CTL-480/S. My installation of Ubuntu 13.04, 64bit, doesn't seem to be able to detect the device. I've tried an few different USB ports on my machine and get the same result.

I believe there is an issue because when I open the System Settings app from the launcher and browse to the Wacom Tablet section under hardware, it reports that there is 'No table detected'.

When I use lsusb I can see the device is detected:
```
Bus 003 Device 004: ID 056a:030e Wacom Co., Ltd
```
I've also pulled the following from the syslog:
```
Oct 16 16:51:05 earth kernel: [ 7062.388031] usb 3-5: new full-speed USB device number 4 using ohci_hcd
Oct 16 16:51:05 earth kernel: [ 7062.611038] usb 3-5: New USB device found, idVendor=056a, idProduct=030e
Oct 16 16:51:05 earth kernel: [ 7062.611042] usb 3-5: New USB device strings: Mfr=1, Product=2, SerialNumber=0
Oct 16 16:51:05 earth kernel: [ 7062.611045] usb 3-5: Product: Intuos PS
Oct 16 16:51:05 earth kernel: [ 7062.611047] usb 3-5: Manufacturer: Wacom Co.,Ltd.
Oct 16 16:51:05 earth mtp-probe: checking bus 3, device 4: "/sys/devices/pci0000:00/0000:00:02.0/usb3/3-5"
Oct 16 16:51:05 earth mtp-probe: bus: 3, device: 4 was not an MTP device
```
I'd really appreciate any suggestions to help debug and install this device.
- Admin over 10 years

  Thanks, I've tried to provide a little more context, see above, as you've suggested.
- Admin over 10 years

  Looks a lot better! +1. Too bad I am unable to provide an answer (I don't have such a device here at hand.)
- Admin over 10 years

  Exactly the same problem on Fedora 19 on my new tablet a few minutes ago. Same tablet, dmesg clearly identifies it. Do you get a wacom driver loaded if you check via lsmod?
- Admin over 10 years

  I've run lsmod and cannot see a wacom driver loaded. Tempted to give upgrading to Ubuntu 13.10 a chance.
- Admin over 10 years

  Installed Ubuntu 13.10 through the Software Updater application (apt-get wrapper) and this has not improved things. FYI, syslog seems to have been deprecated and removed during upgrade.
- Admin over 10 years

  My research shows support for the CTH480 was only added to the driver and kernel in very recent (perhaps still unreleased) versions. I don't expect it's trickled down to distro released versions yet.
- Admin over 10 years

  This forum post indicates support for this model is in the next (as yet unreleased) driver version.
Vadim Peretokin over 10 years

xserver-xorg-input-wacom is 1:0.20.0-0ubuntu1 in Ubuntu 13.10 - would that mean it is supported in 13.10?
Caleb over 10 years

@Vadi version 0.20 didn't come out with support for these tablets until December 6th. I don't know what you are looking at but I suspect that is an OLD version of the xorg driver (current is 0.23), not the new version of the kernel driver.
Admin over 10 years

That interesting, according to the Ubuntu Software Centre, I'm running xserver-xorg-input-wacom 1:0.20.0-0ubuntu1. When I plug the CTL-480 tablet into my machine, it isn't detected by the Wacom Tablet tool in the System Settings application.
Caleb over 10 years

@mjwittering You are confusing the XORG input handler with the kernel device driver. They are two separate components and versioned independently. You may not have a separate package at all for the device driver as is is likely rolled in your kernel package. On Ubuntu I expect this to be taken care of in the next kernel package release (although your xorg package might need to be 0.23 as well).
Admin over 10 years

@Caleb Oh! I see. I've just run uname -r and can see I'm running 3.11.0-14-generic of the kernel. Is that the most recent version?
Caleb over 10 years

@mjwittering The latest kernel is currently 3.12.6, so no, not by a long shot. That being said distros like Ubuntu tend to run a few versions back most of the time due to their testing cycle but they sometimes backport device drivers. I don't know what version is current for your distro release or when you will see the drivers come down the pipe.
