How to create a virtual printer in Windows?

40,028

Solution 1

When I did it (which about 12 years ago) I started with the postscript driver sample, replaced all the postscript-specific stuff (in my case, to write to a bitmap instead of generating postscript commands).

I also wrote a custom print monitor (the driver writes to the spooler, which write to a monitor): my monitor wrote to a file instead of e.g. to the parallel port.

However, printer driver architecture and/or the set of sample drivers may have changed since then.

Solution 2

You can look to the 'minidriver' development in the from Microsoft (Microsoft MDT), that might help depending on your exact needs. If the port you need to deal with (ie: you are going to take the data from an existing printer driver and want to process) you could look to the source code for RedMon. It doesn't support Vista/Win7 but might point you in the right direction.

Solution 3

This book maybe help you Developing Drivers with the Windows® Driver Foundation

A list of my links

Solution 4

One of the drivers you mention is open-source (GPL), maybe you could explore its source or adapt it: http://www.pdfforge.org/products/pdfcreator/download

Solution 5

Someone else already mentioned PDFCreator. Here's a more specific link to their code that's creating the printer, port and monitor. Despite being in VB, I can follow it as someone more used to C++, so I guess you can too. modPrinter.bas does the leg work. modMain.bas, from about line 28 onwards, calls into modPrinter.bas.

View more solutions

40,028

Terminus

Updated on March 28, 2020

Comments

Terminus over 2 years

I want to create a virtual printer driver for Windows. How and where can I start properly? The WDK has some printing drivers examples that do not seems a good introductory. MSDN also doesn't seems to be very helpful for a novice.

There are a lot of virtual printers for Windows out there (mostly they generate PDFs), I wonder if someone could tell my how can I do the same?

Any links to the elaborating documentations are appreciated in advance.

Thanks.
- John Saunders about 13 years

  You might get more help if you said what problem you have that is not addressed by the sample drivers.
- Terminus about 13 years

  They are a good starting point if you want to develop "real" drivers but they are not as helpful if all you need are "virtual", non-hardware based drivers. The bitmap sample is the most helpful, though.
Terminus over 13 years

Unfortunately (most of it?) is written in Visual Basic. If there were one written in C/C++... :-).
ChrisW over 13 years

That may not be the printer driver; its directories like "Version 0.9.8\Printer\Adobe\WinXP2k3-x86\English" are empty, so far as I can see, except for a readme. Maybe the VB is some kind of front end to GhostScript, available separately.
ChrisW over 13 years

The contents of "Version 0.9.8\Printer\Adobe\WinXP2k3-x86\English\readme.txt" is "psui.dll", "pscript5.dll", and "pscript.hlp"; these filenames suggests to me that these driver files too were created from the postscript sample driver.
ChrisW over 13 years

Yes, the 'virtual' (non-hardware) part is the monitor not the driver. The driver controls the format of the output (not the output's location/destination)
Terminus about 13 years

Userspace only in post-Vista -- I need to support Windows 2000.
Terminus about 13 years

Well, I already have that book. The problem is not developing drivers, the problem is finding specific information relevant to developing the kind of Virtual Printer drivers that I want.
Mooing Duck over 8 years

Link #4 is now broken unfortunately. What was that?
Mooing Duck over 8 years

Would be more helpful to link to the source instead of the company that funds it
