Trouble creating PID file in systemd service script

Question

I'm trying to get RipRight installed on Debian, for which there doesn't appear to be any pre-built package. I'm having difficulty getting a systemd script working to start/stop RipRight running as a daemon because it can't write the PID file to /run.

I went through the usual configure/make/make install. I also created a ripright user/group and added ripright to the cdrom group.

Here is the systemd script I placed in /etc/systemd/system/ripright.service:

[Unit]
Description=RipRight
[Service]
Type=forking
PrivateTmp=yes
User=ripright
Group=ripright
RuntimeDirectory=ripright
RuntimeDirectoryMode=0750
ExecStart=/usr/local/bin/ripright \
    --daemon \
    --w32-filenames \
    --require-art \
    --folder-art folder.png \
    --output-file "%B/%D/%C - %N %T.flac" \
    "/opt/ripright/data"
PIDFile=/var/run/ripright/ripright.pid
[Install]
WantedBy=multi-user.target

I used the recently-added RuntimeDirectory directive in the script to create a /run/ripright folder with ripright as the owner. This directory gets created when I run:

# systemctl daemon-reload
# systemctl start ripright

In a separate window:

# ls -lhrt /run
...
drwxr-x---  2 ripright ripright   40 Jan  5 20:52 ripright
drwxr-xr-x 16 root     root      400 Jan  5 20:52 systemd
# ls -lahrt /run/ripright
total 0
drwxr-xr-x 16 root     root     540 Jan  5 20:52 ..
drwxr-x---  2 ripright ripright  40 Jan  5 20:52 .
# su - ripright
$ cd /run/ripright
$ pwd
/run/ripright
$ echo test > one.txt
$ cat one.txt
test
$ rm one.txt
$ exit

I believe my systemctl start command does not return due to this and instead hangs. After a minute or so, it times out with:

# systemctl start ripright
Job for ripright.service failed. See 'systemctl status ripright.service' and 'journalctl -xn' for details.

Here is the output of the recommended commands:

# systemctl status ripright.service
● ripright.service - RipRight
   Loaded: loaded (/etc/systemd/system/ripright.service; enabled)
   Active: failed (Result: timeout) since Thu 2017-01-05 20:54:40 EST; 55s ago
  Process: 35396 ExecStart=/usr/local/bin/ripright --daemon --w32-filenames --require-art --folder-art folder.png --output-file %B/%D/%C - %N %T.flac /opt/ripright/data (code=exited, status=0/SUCCESS)
 Main PID: 33287 (code=killed, signal=TERM)
Jan 05 20:53:10 ripperd ripright[35397]: Started daemon mode (v0.11)
Jan 05 20:53:10 ripperd ripright[35398]: Waiting for a CD (/dev/cdrom)
Jan 05 20:54:40 ripperd systemd[1]: ripright.service start operation timed out. Terminating.
Jan 05 20:54:40 ripperd systemd[1]: Failed to start RipRight.
Jan 05 20:54:40 ripperd systemd[1]: Unit ripright.service entered failed state.
# journalctl -xn
-- Logs begin at Thu 2017-01-05 00:30:29 EST, end at Thu 2017-01-05 20:54:40 EST. --
Jan 05 20:52:00 ripperd ripright[35380]: Waiting for a CD (/dev/cdrom)
Jan 05 20:52:59 ripperd su[35385]: Successful su for ripright by root
Jan 05 20:52:59 ripperd su[35385]: + /dev/pts/1 root:ripright
Jan 05 20:52:59 ripperd su[35385]: pam_unix(su:session): session opened for user ripright by vagrant(uid=0)
Jan 05 20:53:10 ripperd ripright[35397]: Started daemon mode (v0.11)
Jan 05 20:53:10 ripperd ripright[35398]: Waiting for a CD (/dev/cdrom)
Jan 05 20:53:33 ripperd su[35385]: pam_unix(su:session): session closed for user ripright
Jan 05 20:54:40 ripperd systemd[1]: ripright.service start operation timed out. Terminating.
Jan 05 20:54:40 ripperd systemd[1]: Failed to start RipRight.
-- Subject: Unit ripright.service has failed
-- Defined-By: systemd
-- Support: http://lists.freedesktop.org/mailman/listinfo/systemd-devel
--
-- Unit ripright.service has failed.
--
-- The result is failed.
Jan 05 20:54:40 ripperd systemd[1]: Unit ripright.service entered failed state.

If I comment out the PIDFile directive in the systemd service script:

#PIDFile=/var/run/ripright/ripright.pid

Then I have no problems, but also no PID file as recommended for a service type of forking:

# systemctl daemon-reload
# systemctl start ripright
# ps -ef | grep ripright
ripright  35438      1  0 21:03 ?        00:00:00 /usr/local/bin/ripright --daemon --w32-filenames --require-art --folder-art folder.png --output-file %B/%D/%C - ripright %T.flac /opt/ripright/data
ripright  35439  35438  0 21:03 ?        00:00:00 /usr/local/bin/ripright --daemon --w32-filenames --require-art --folder-art folder.png --output-file %B/%D/%C - ripright %T.flac /opt/ripright/data
root      35442  31942  0 21:03 pts/0    00:00:00 grep ripright
[email protected]:~# systemctl status ripright
● ripright.service - A minimal CD ripper for Linux modeled on autorip.
   Loaded: loaded (/etc/systemd/system/ripright.service; enabled)
   Active: active (running) since Thu 2017-01-05 21:03:11 EST; 13s ago
  Process: 35437 ExecStart=/usr/local/bin/ripright --daemon --w32-filenames --require-art --folder-art folder.png --output-file %B/%D/%C - %N %T.flac /opt/ripright/data (code=exited, status=0/SUCCESS)
 Main PID: 35438 (ripright)
   CGroup: /system.slice/ripright.service
           ├─35438 /usr/local/bin/ripright --daemon --w32-filenames --require...
           └─35439 /usr/local/bin/ripright --daemon --w32-filenames --require...
Jan 05 21:03:11 ripperd ripright[35438]: Started daemon mode (v0.11)
Jan 05 21:03:11 ripperd ripright[35439]: Waiting for a CD (/dev/cdrom)
# ls -la /run/ripright
total 0
drwxr-x---  2 ripright ripright  40 Jan  5 21:04 .
drwxr-xr-x 16 root     root     540 Jan  5 21:04 ..
# systemctl stop ripright

Interestingly enough, when I brought PIDFiles back in and commented out User and Group to run ripright as root, daemon-reloading and then starting the script still hangs:

#User=ripright
#Group=ripright
PIDFile=/var/run/ripright/ripright.pid

The same thing happens if I leave User and Group commented out and set PIDFile to produce the PID file directly in the /run directory (noting /var/run is simply a symlink to /run in Debian Jessie):

#User=ripright
#Group=ripright
#PIDFile=/var/run/ripright/ripright.pid
PIDFile=/run/ripright.pid

Note in all cases I can press Ctrl+C during the hang and the ripright daemon will continue to run; however, if I let the start time out, it'll stop the daemon before printing the error and returning.

I also went through this post and its comments. The initial approach of using ExecStartPre had the same results; I did not get far with using tmpfiles.d as I couldn't find any information on how to make the changes take effect without rebooting. I tried mount -a but that didn't seem to work.

Solution 1

If you're asking if systemd will create a PID file for the daemon, it will not, per:

https://www.freedesktop.org/software/systemd/man/systemd.service.html#PidFile=

PIDFile=

Takes an absolute file name pointing to the PID file of this daemon. Use > of this option is recommended for services where Type= is set to forking. systemd will read the PID of the main process of the daemon after start-up of the service. systemd will not write to the file configured here, although it will remove the file after the service has shut down if it still exists.

It might be better to leave it blank and try using GuessMainPID=.

Solution 2

Regrettably, systemd won't create a PID file for a non-forking service even if you specify a PIDFile= line in the service's unit file. But you may be able to cheat with a ExecStartPost= line, such as:

ExecStartPost=/bin/sh -c 'umask 022; pgrep YOURSERVICE > /var/run/YOURSERVICE.pid'

Comments

[Admin]

How did you configure ripright to create a PID file? I could not find this anywhere in your question.

[Admin]

I didn't. The application needs to create the PID file? I see nothing in ripright's documentation or options, and it doesn't look like the source code is doing this at all. What if the application isn't written to create a PID file? Am I supposed to do so in the systemd service script, or in some wrapper script?

[Admin]

If the ripright program doesn't create a PID file, then you don't need to do anything. See serverfault.com/a/817560/126632

[Admin]

Looks like this will work for me; if you want to formulate this as an answer, I'll accept it.

[Michael Hampton]

systemd doesn't create PID files at all. That's the responsibility of the service. As discussed previously, that's not what PIDFile= is for.

[John Hascall]

Alas, it's too bad that systemd can't be requested to write/delete pidfiles for Type=simple services as it is most in possession of the info to do so.
